WTL часы осциллятор для мобильного телефона WTL HC49/S DIP 30ppm 30pF 10 МГц кварцевый кристалл
- Category: Crystals, Oscillators and Resonators >>>
- Supplier: WTL International Limited
Share on (62488330160):
Product Overview
Description
Product Description
o Electrical Specifications | ||||||
Item | Specifications | |||||
Frequency Range(MHz) | 8^10 | 10^24 | 24^104 | |||
Mode | AT/Fundamental | |||||
Load Capacitance (CL) | 8pF,9pB 10pB 12pB 18pB20pB or Specify | |||||
Frequency Tolerance( at25°C) | ±10ppm ~ ±30ppm or specify | |||||
Operating Temperature Range | -20~+70°C or Specify | |||||
Frequency Stability Over Operating Temperature Range | ±10ppm ~ ±30ppm or specify | |||||
Equivalent Series Resistance (ESR) max. | 200Ω | 80Ω | 60Ω | |||
Storage Temperature Range | -55~+125°C | |||||
Shunt Capacitance! C 0) | 3pF Max | |||||
Drive Level (Typical) | 1-100 pW (50pW typical) | |||||
Aging @25°C 1st Year (Max) | ±3 ppm/year max | |||||
3.2×2.5×0.7 mm
Feature\u2029
● Size 3.2×2.5, Ultra thin,thickness0.7mm
●High precision and high frequency stability
●Excellent heat resistanceandenvironmental characteristics
●Designed for automaticmounting and reflowsoldering
●RoHS Compliant /Pb Free
