Mosquito Holder Titanium Ophthalmic Surgical Instruments TH-11415-1
US $25.00-$31.20
supplier Operating Microscope for eye
- Category: Microsurgery Equipments >>>
- Supplier: Qingdao Dacon Trading Co. Ltd. [Shandong China]Qingdao
Share on (62490339033):
Product Overview
Description
Operating microscope for eye
Product Description
The product is an advanced double binocular operation microscope designed for two men, It is used for eye operation.
|
Eyepiece Magnifications |
12.5×/18B |
|
Objective Lens |
f=200 |
|
Working Distance |
170mm |
|
Magnification for Main Microscope |
4.6×~27× motorized and manual control continuous magnification |
|
Magnification for Assistant Microscope |
6×,10×,16× |
|
Diameter of Field |
4646+46mm~8.58.588.58mm |
|
Diopter Adjustment |
±7D |
|
Pupil Distance |
50mm ~ 75mm (main microscope is 45mm ~ 80mm) |
|
Maximal Resolution |
119 LP/mm |
|
Focusing Range for Assistant Microscope |
≥30mm |
|
Illumination Source |
12V/100W,cold reflection halogen lamp for medical use |
|
Illumination Type |
6°+0°coaxial illumination of cold light source, 26°oblique illumination. |
|
Coaxial Illumination |
≥80000lx,1~9level,panel operated. |
|
Oblique Illumination |
≥60000lx,1~9level, panel operated |
|
Reaching Radius of Arm |
1230mm |
|
Adjustable Vertical Range |
880mm~1420mm. |
|
Fine Focusing Speed and Range |
≤2mm/s,≥50mm |
|
Speed for X/Y and Range |
≤2mm/s,50mm×50mm. |
|
Input Voltage |
AC220V±22V/50Hz±1Hz, AC110V±11V/60Hz±1Hz. |
|
Power |
170VA |
|
Fuse |
AC250V T4.04.0444.0000A ,AC1250V T8.0588.0A |
|
Electrical Safety Standard |
Executive standard:GB9706.1-2007,Class |
Packaging & Shipping
| Quantity | Delivery method |
| Small packing | Send by express, such as EMS, TNT, FedEX, Post Office, etc. |
| Goods over 50 kgs | Send by exress or by air |
| Large quantity | Send by sea, by air, etc. FCL/ LCL |
********************************************************************
Our company have our own dehydrating and processing factory of zibo dacon natural products co.,ltd ,who specialized in producing the agricutural products ,dried vegetables ,fruits,spice ,herbs and plant extracts etc ,
we are also the main supplier of foods materials and food additives ,supplements ,vitamins ,amino acids.chemicals and pharmaceutical materials medical equipments and supplies etc with about 40 years experience
