Product Overview
Description
Tissue machine/paper machinery/toilet paper machine/toilet paper making machine/ toilet roll making machine/perforating machine/Small toilet paper making machine
Toilet Machine,Toilet Paper Rolls,toilet paper machine ,roll paper plant equipment
CDH-2600 YQ
Full Automatic Toilet Paper Kitchen Towel Production Line
First Part:
Rewinder Machine
Main Technical Parameter | |
Electric source | 380V, 50Hz, 3 PH |
Finished Roll Diameter | 90-150mm |
Finished Roll Core Diameter | Φ 48 mm |
Raw Material Diameter | ≤Φ 1100 mm (Other sizes can be customized) |
Raw Material Core Diameter | 3”(76.2 mm) (Other sizes are available ) |
Width Of Raw Material | 2600mm, only for producing kitchen paper roll |
GSM of raw paper | 19-25g |
Perforating Pitch | 105~160mm |
Speed | 0-200 meters/min |
Parameter Setting | Touch button LCD Screen operation panel |
Program Controller | Programmable Controller (PLC) |
Mechanism Driving | |
Embossing Roller | Polyurethane embossing roller |
Embossing type | Point to point |
Color unit | Without color printing |
Lamination unit | With lamination |
accumulator | One set |
40 pieces shelves which can be store 20 pieces of finished roll | |
Unwinding Paper Stand | 2 |
Power | Variable frequency speed control, 32KW |
Machine Size | 9500×3100×2200mm(L×W×H) |
Weight | 12000kg |
Second Part:
CDH-203 Paper storage rack
model | CDH-203 |
toilet roll length | 2600mm( Other specifications need to custom-made ) |
toilet roll diameter | Φ95mm~Φ140mm |
Store paper quantity | 0-63 rolls |
Store speed | 40 rolls/min |
Store paper quantity | Optional 40 to 400 paper roll (Specifications need to be custom-made) |
Machine size | 4000*3000*5500mm (Specifications according to the actual size) |
PLC | PLC(Delta) |
Third Part:
Log Saw machine
Model | CDH-150 |
Length of toilet roll | 2mm ( Other specifications need to custom-made ) |
toilet roll diameter | Φ105~φ115mm ( Other specifications need to custom-made ) |
design speed | 120 cut /min |
stable speed | 100 cut /min |
Sharpen system | Pneumatic, grinding time interval is adjustable |
Driving system | Delta servo motors |
power | 11KW |
machine size | 6500*2500*2000mm ( Other specifications according to the actual size ) |
blade size | φ610*4.7(mm) |
voltage | 380V 50HZ |
machine weight | 4.5T |
Fourth Part:
Rolls/pack packing machine
power | 220V 50HZ |
The main circuit power | 0.74KW |
The sealing seal cutting power transformer | 0.45KW |
total power | 1.19KW |
air pressure | 0.4---0.5MPA |
