P 0.935 Indoor Full Color LED Display Parameter | ||||
(1)Parameter of Pixel | ||||
Number | Item | Parameter | ||
1 | Pixel Pitch | 0.935mm | ||
2 | Pixel composition | 1R1G1B | ||
(2)Parameter of Chip | ||||
Number | Item | Wave length | Brightness | Specification |
1 | Red Chip | 620-624nm | 82-102mcd | COB |
2 | Green Chip | 521-525nm | 220-275mcd | |
3 | Blue Chip | 468-472nm | 48-60mcd | |
(3)Display Technical Parameters | ||||
Lamp | LED Specification | COB | ||
Module
| Module Size | W160mm*H180mm | ||
Module Resolution | W150Dots*H168.75 Dots | |||
Scanning Mode | 60s | |||
Working Voltage | DC 5V | |||
Module Power | 25W | |||
Cabinet
| Standard Size | 600*337.5mm | ||
Ingress Protection | IP40 (Front) /IP40 ( Rear) | |||
Cabinet Resolution | 642*361 Dots | |||
Cabinet Material | Diecast Cabinet | |||
4 | LED Driver | Constant Current | ||
5 | Pixel/ M2 | 1137777Dots/ M2 | ||
7 | Display Brightness | Maximum 1200cd/m2 | ||
8 | Viewing Angle | Horizontal 160° Vertical 160° | ||
9 | Best Viewing Distance | ≥0.935m | ||
10 | Grey Level | 16bit | ||
11 | Display Color | 16.7M | ||
12 | Color Quality | 32 Bits | ||
13 | Frame Changing Frequency | |||
14 | Refresh Rate | >3840HZ | ||
15 | Life Time | >100000 Hours | ||
16 | Blind Spot Rate | < 2/10000 | ||
17 | Working Voltage | AC220V±15% 47~64HZ | ||
18 | Maximum Power Consumption ion | 600W/ M2 | ||
19 | Average Power Consumption | 200W/ M2 | ||
20 | Continuous Working Time | >48 Hours | ||
21 | MTBF | >10000 Hours | ||
22 | Operating Temperature | -10℃~+60℃ | ||
23 | Operating Humidity | 10%-95%RH | ||
24 | System Operating Platform | WINDOWS XP | ||
25 | Control Mode | Synchronous/ Asynchronous System |
