High accuracy 32 42 inch interactive touch foil.
- Category: Projection Screens >>>
- Supplier: Quanzhou Greatouch Technology Co. Ltd.
Share on (62495086182):
Product Overview
Description
Wholesale glass windows sensitive to touch 32'' interactive touch foil
Product Description
Features & advantage:
1.Stable quality,9 years life time.
2.Zero pressure and precise touch,fast response.
3. The size can be customized.
4.Water-proof, Ultraviolet-proof, Vandal resistant,easy clean.
5.Suitable for different environment of indoor and outdoor.
6.Flexible,could be used in innovative design and special construction .
7.Fashionable and beautiful appearance,frameless,transparent, ultrathin design.
8.The same technology of projected capacitive touch as IPAD,maximum supports 100 points now .
9.Work through galss maximum thickness of 12mm .
2.Zero pressure and precise touch,fast response.
3. The size can be customized.
4.Water-proof, Ultraviolet-proof, Vandal resistant,easy clean.
5.Suitable for different environment of indoor and outdoor.
6.Flexible,could be used in innovative design and special construction .
7.Fashionable and beautiful appearance,frameless,transparent, ultrathin design.
8.The same technology of projected capacitive touch as IPAD,maximum supports 100 points now .
9.Work through galss maximum thickness of 12mm .
Specification:
| Available size | 32-65 inch | Touch points | ≤10 points |
| Series | ME-A | Touch deviation | ≤1mm |
| The number of sensors | TX40 RX96(≤50inch)TX58 RX96(>50inch) | Scanning speed | 10ms /frame |
| Energy consumption | 1.5W | Drive Type | Drive Free |
| Arm Reject | Yes | Custom | not support custom |
| Point report Rate | >100 | Film thickness | ≤100um |
| Light transmission rate | Above 93% | Supply voltage | 5V USB |
| Transmission | USB2.0 | Warranty | 1 Year |
| Program-level | Kernel-level low-level drive | Technical certification | CE,ilac-MRA,CNAS,CAL,CMA |
| Ambient temperature | -20℃ to +70℃ | Ambient lightness | Whole angle of the anti-glare |
| Touch support | Click, drag, zoom, rotate | Sensing distance | ≤20mm( glass thickness ) |
| Calibration mode | Software calibration | Program type | Andriod,Linux,Mac,Windows7/8/8.1/10( see note) |
| Transmission distance | ≤50m ( plus USB signal amplifier, etc ) | Safety distance | 2mm( refers to the distance between the LCD screen and the film) |
| Packing List | 1 * touch film circuit/ control board * 1 /USB cable * 1 | ||
Touch membrane principle:
Application
The capacitive touch screen has been used in many areas, such as office, teaching, entertainment equipment and so on.
<
Related product
The following is our other hot products, welcome to click to view.
Company Information
Our partner
Packaging & Shipping
FAQ
Q1: Are you a factory or a trading company?
A: We are a OEM/ODM factory.
Q2: What payment methods your company accept?
A: We accept most of the payment methods,but mainly accept T/T,Paypal and Western Union.
Q3: How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery.
Q4: What will you do if the product be nature damange within warranty time and how about out that time?
A: Well, we will give some quite simple questions to help us confirm the damaged part. Once it confirmed, the free replacement will be send. Also, we will just request a very low price for replacement part, if the product out of warranty time.
Q5: Do you give any discount?
A: I'll surely try my best to help you get those by the best price and good service at the same time.
Q6: Can I customize the product I ordered?
A: Abusolutely yes, customizatiion offer from customers are most welcome in our company.
