Lab Pilot with MF,UF,NF,RO Polymeric Membrane Spiral Wound Membrane for Separation and Concentration

Product Overview

Description



Lab Pilot with MF,UF,NF,RO Polymeric Membrane Spiral Wound Membrane for Separation and Concentration



1: Item No.: DQPM

2: MF: 0.1um-5um

    UF: 0.01-0.1um

    NF: <0.001um

    RO: <0.001um

3: The membrane element in this pilot can be replaced with MF,UF,NF and RO membrane.



Comparison between four membrane processes
	Reverse osmosis	Nanofiltration	Ultrafiltration	Microfiltration
Membrane	Asymmetrical	Asymmetrical	Asymmetrical	Symmetrical Asymmetrical
Pore size	<0.001um	<0.001um	0.01-0.1um	0.1-5um
Rejection of	HMWC,LMWC Sodium chloride Glucose Amino acids,...	HMWC Mono-,di- and Oligosaccharides Polyvalent neg. Ions,...	Macro molecules, Proteins, polysaccharides, Vira ...	Particles,clay, Bacteria, ...
Membrane material	CA Thin film	CA Thin film	Ceramic, PVDF,PSO,CA, Thin film	Ceramic, PVDF,PSO,PP, PES



4:Selection of membrane material:

 Except for established applications,the choice of membrane material may be difficult,

    and more than one membrane material often comes into question.

    As a general rule,only well planned and well performed pilot tests will provide good

    answers to membrane selection questions for given processes.



     5:Applications:

     This pilot can be used for experiment of filtration,separation,clarification,and

     concentration.

      All the data got from this pilot can be copied for big plant manufacturing.



Zibo Dongqiang Ceramic Filter Co.,Ltd. is a specialized manufacturer of inorganic ceramic membrane and polymeric membrane and equipment and solution provider of membrane filtration,separation,concentration and extraction technology.

We have a R&D center,6 ceramic membrane production line,2 polymeric membrane production line,1 housing fabricating workshop,1 equipment assembly and fabricating workshop.

With the above production capacity and expertized staff,our business ranges from MF,UF,NF,RO membrane and euqipment manufacturing to the complete process development,engineering design,system integration,assembly and commissioning.

We supply our customers with:

1:Membrane module:

  Ceramic membrane,polymeric membrane and housing.

2:Membrane equipment:

  Lab scale pilot,Middle scale pilot,and industrial scale equipment.

3:Membrane technology solution:

  Water treatment,Environmental protection,Food and beverage,

Biochemical,Pharmaceutical,Oil field industries.

4:Membrane technology and service.



*The above is a general introduction of our lab test pilot.

For more detailed information,pls contact us.
