High efficiency Oil fired boiler / energy saving gas fired boiler

Product Overview

Description

Our company supplies WNS series ultra-low nitrogen fully condensed steam/hot water boiler, WNS series ultra-low nitrogen oil (gas) steam/hot water boiler, WNS series oil (gas) condensed steam/hot water boiler, SZS series oil (gas) steam/hot water boiler, DRS oil (gas) conduction oil boiler, flue gas waste heat steam boiler etc.

WNS series ultra-low nitrogen fully condensed steam/hot water boiler

1.Principle

Through the heat exchange between low temperature water and flue gas, the temperature of flue gas is reduced to the temperature at which vapor in the flue gas condenses into liquid water. The principle of utilizing the latent heat of gasification released during the condensation of vapor, the higher the condensation rate, the higher the corresponding boiler efficiency.

2.Technical characteristics

Ultra-low nitrogen emission, high thermal efficiency, low exhaust gas temperature, integration of boiler main part, enhanced heat transfer of corrugated boiler flue, thermal expansion compensation measures, three-layer insulation materials, fully automatic intelligent control, etc.

3.Parameter characteristics

Model: WNS1~20 (horizontal)

Working pressure: 1.0~2.0Mpa

Steam output: 1T~20T/H

Applicable fuel: natural gas, city gas, light diesel etc.



 WNS series ultra-low nitrogen oil (gas) steam/hot water boiler

1.Principle

According to the requirements of customers in different industries, we provide customers with solutions that are safe, reliable, energy-saving (heat efficiency up to 95%) and low nitrogen <30mg/Nm3. It mainly uses the ultra-low nitrogen combustion device and the reuse of the waste heat flue gas to control the flue gas in the furnace to a reasonable temperature range to meet the emission requirements.

2.Technical characteristics

Ultra-low nitrogen emission, high thermal efficiency, integration of boiler main part, enhanced heat transfer of corrugated boiler flue, thermal expansion compensation measures, three-layer insulation materials, strong overload capacity, fully automatic intelligent control, etc.

3.Parameters characteristics

Model: WNS0.5~20 (horizontal)

Working pressure: 1.0~2.5Mpa

Steam output: 0.5T~20T/H

Applicable fuel: natural gas, city gas, light diesel etc.



WNS series oil (gas) condensed steam/hot water boiler

1.Principle

It absorbs the design concept of European advanced condensed boiler, it adopts the eccentric low-position arrangement method and the specially designed two-return enhanced heat transfer structure, it combines the integrated design of energy saver and condenser.

2.Technical characteristics

Full condensation, high thermal efficiency, low exhaust gas temperature, integration of boiler main part, enhanced heat transfer of corrugated boiler flue, thermal expansion compensation measures, three-layer insulation material, durable, fully automatic intelligent control, etc.

3.Parameter characteristics

Model: WNS1~20 (horizontal)

Working pressure: 1.0~2.5Mpa

Steam output: 1T~20T/H

Applicable fuel: natural gas, city gas, light diesel, dual-fuel of natural gas/light oil etc.



 SZS series oil (gas) steam/hot water boiler

1.Principle

It adopts double-cylinder structure and full membrane wall design. The high-temperature flue gas is surrounded by the sealed membrane wall. It overcomes the defects that the conventional boiler is not completely sealed and leaks smoke, ensuring the efficiency and safe operation of the boiler.

2.Technical characteristics

Ultra-low nitrogen emission, high thermal efficiency, air tightness guarantee, water cycle safety, thermal expansion compensation measures, three-layer insulation material, convenient maintenance, fully automatic intelligent control, etc.

3.Parameter characteristics

Model: SZS20~100

Working pressure: 0~9.9Mpa

Steam output: 20T~100T/H

Applicable fuel: natural gas, city gas, light diesel etc.



 DRS oil (gas) conduction oil boiler

1.Principle

An energy-saving and eco-friendly product integrating electromechanical, combustion and heat exchange. The boiler adopts a modular design, and compact spiral coils are installed in the body. The boiler is fully covered by oil pipes. Combined with an efficient full oil-cooled fireplace tube, ensuring the boiler thermal efficiency and environmental emissions.

2.Technical characteristics

Heating temperature up to 400 ℃, high energy-saving efficiency, uniform heating, fast-mounted structure, multi-coil and multi-return structure, thermal expansion compensation measures, three-layer insulation material, durable, fully automatic intelligent control, etc.

3.Parameter characteristics

Model: DRS5~2000 (horizontal)

Working pressure: 1.0Mpa

Rated output: 50,000~20,000,000 Kcal/H

Applicable fuel: natural gas, city gas, light diesel, heavy oil, dual fuel of natural gas/light oil etc.



 Flue gas waste heat steam boiler

1.Principle

According to the customer's various special requirements and working conditions, the waste heat of the flue gas in the process gas is reasonably used to generate the steam, so as to meet the process.

2.Technical characteristics

High-temperature waste heat boiler, medium/low-temperature waste heat boiler, low-temperature section using anti-corrosion materials, automatic ash removal device

3.Parameter characteristics

Working pressure: 0.5~2.0Mpa

Rated output: 0.5~20T/H steam

Applicable fuel: natural gas, city gas, light diesel, heavy oil, dual fuel of natural gas/light oil, coal (biomass) etc.
