86 Inch convert smart tv into tactile infrared touch panel for whiteboard
Product Description
| Specification: | |||
| Size rang | 15 inch To 700 inch | Touch technology | True multi-point touch screen |
| Touch pressure | Zero pressure | Surface durability | 7H |
| Storage temperature | —40℃-85℃ | The report resolution | 32767×32767 |
| Interface | USB2.0 HID mode | Scanning speed | 50 frames per second |
| Apply liquid crystal size | 15'' - 700'' | Temperature range | 0 ℃ to 50 ℃ |
| Object shape recognition | Support | Average current | <200mA |
| Power consumption | 1W | Maximum current | <350mA |
| Dormancy current | <10mA | Response speed | 8ms |
| Maximum recognition point size | 8mm×8mm | Minimum contact detection | 3mm |
| Humidity range | 90% RHd 40 ℃ without dewing | Working voltage | 5.0 V (internal voltage of 3.3 V) |
| Touch mode | Fingers, pen (not capacitance, electromagnetic pen) | ||
| Light transmittance | Transmittance of 100% to 100% (no glass) | ||
| Support platform | Windows xp\\windows7\\8\\linux\\android | ||
| Interference by | No electrostatic interference, drift phenomenon | ||
| Touch point recognition | Touch point: 4 points, 6 points,10 points, 16 points, 20 points,32 points | ||
| Resistance to bad environment | Redundancy is extremely high, 20% sensor damage, still can keep the multi-point touch | ||
Products Advantage:
1.Infrared multi touch frame ,supports 2,6,10,16,32 precise touch points ,Driver free
2.USB plug and play,Sizes from 15" to 700" (4:3 ,16:9, 16:10)
3.Custom Sizes Available,Easy to Install
4.Waterproof optional,High Stability / Reliability
5.Extremely Durable / Scratch Resistant
6.Compatible with Win7, Win8, Win10, Android, Linux system
7.Simple calibration
2.USB plug and play,Sizes from 15" to 700" (4:3 ,16:9, 16:10)
3.Custom Sizes Available,Easy to Install
4.Waterproof optional,High Stability / Reliability
5.Extremely Durable / Scratch Resistant
6.Compatible with Win7, Win8, Win10, Android, Linux system
7.Simple calibration
Products Show:
Application
Apply to TV/monitor/kiosk/projection screen, turn the equipment from non-touch to touch.
