CCS2 EVSE Charging Connector

Product Overview

Description

Workersbee DC EV charger type 2 80A CCS2 combo2 EV charging plug connector

Rated current have 150A and 200A, have shield wire.

Rated Current	Rated Voltage	Cable Specification
60A/80A	1000V	2*16+1*25+6*0.75mm2
125A/150A	1000V	2*50+1*25+6*0.75mm2
200A	1000V	2*70+1*25+6*0.75mm2





Color: white or black

Rated current: 80A

Rated voltage: 1000V

Certificate: CE

Standard: IEC62196-3

Warranty: 1 Year

Protection Degree: IP65

Operating temperature: -30℃-+50℃

Material: Thermoplastic UL94 V-0

Function: DC charger connector
