Hoston Semi-automatic Gear Hobbing Machine Y3150/3180
US $5600-$6000
HOT Selling Factory Price Gear Hobbing Machine /Gear Hobber
- Category: Gear Cutting Machines >>>
- Supplier: Henan Wadley CNC Machinery Co. Ltd.
Share on (62502223557):
Product Overview
Description
Product Description
HOT Selling Factory Price Gear Hobbing Machine Gear Hobber
Detailed Images
Size Information
Index name | unit | ||
Max machining diameter | With rear column | 1000mm | |
Without rear column | 1250mm | ||
Max modulus | Steel | 12mm | |
Cast iron | 16mm | ||
Max machining width | 450mm | ||
Max diameter/length of hob | 245/220mm | ||
Worktable diameter | 950mm | ||
Scope of main tool turning speed and grade | 16-125rpm/7 | ||
Arbor diameter | 27/32/40/50mm | ||
arbor diameter of work piece | 60mm | ||
Max axial travel of tool | 100mm | ||
Max turning angle of hob | ±60° | ||
Worktable aperture | 200mm | ||
Main motor | 11kw | ||
Spindle taper | Morse 6 | ||
Distance from hob center to worktable face | 200-700mm | ||
Distance from hob center to worktable axes center | 100-750mm | ||
Machine size(length× width× height) | 3700×2040×2400mm | ||
Weight | About 13000kg | ||
Company Introduction
FAQ
Q1.How to send my enquiry?
You can contact us by email, phone call, message (Whats APP, We Chat, Skype).
Q2.How long can I get feedback after enquiry?
We will reply you within 3 hours in working day.
Q3.Delivery time
Machines order takes 30 days after deposit payment received. Please inquiry sales.
Q4.What is the package? Is it suitable for shipment?
Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong
for oversea transportation.
Q5.Payment term
30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to
inquiry sales.
Q6.How long is the warranty for machines?
Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing.
Q7.Can you engineer come to our place to help with machine installation & commission?
Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
You can contact us by email, phone call, message (Whats APP, We Chat, Skype).
Q2.How long can I get feedback after enquiry?
We will reply you within 3 hours in working day.
Q3.Delivery time
Machines order takes 30 days after deposit payment received. Please inquiry sales.
Q4.What is the package? Is it suitable for shipment?
Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong
for oversea transportation.
Q5.Payment term
30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to
inquiry sales.
Q6.How long is the warranty for machines?
Machines warranty is 12 months after receive goods. in Warranty time,we can provide new free parts for changing.
Q7.Can you engineer come to our place to help with machine installation & commission?
Yes, our engineers are available to travel to your place. Round flight tickets & accommodation will be at your cost.
