LTO battery is named Lithium titanate battery(Li4Ti5O12), is a new generation lithium ion battery that used the LTO as cathode material instead of graphite, the anode can be LiCoO2, LiMn2O4, LiFePO4,and NiCoMn. as a new type rechargeable lithium battery, LTO battery has great performances of perfect high safety, high stability, super long cycle life, fast charging/discharging performance, and strong temperature tolerance.
It can be widely used in electrical vehicles, city buses, charging station, ESS, Solar/Wind Energy Storage System, UPS, back-up power, Telecommunication, Home Solar Energy Storage System, Car Audio, Car Starter, Forklift, etc.
Lithium Battery Five Worldwide Challenges
1. High Safety: With spinel structure and zero strain material, No SEI layer occurs, ZERO EV accident worldwide, and No fire or explosion even after steel needle penetration, sea water submerging, cutting or burning testing, etc. 2. Long Circle Life: 80% capacity after 25,000 times life for 100% DOD charging/discharging. First 10 years used on electrical vehicles and also another 20 years on energy storage system products. 3. High Power: Large power similar to super capacitor. Have great advantages on grid peak load and frequency regulation.
4. Fast Charging/Discharging: 10 times capacity charging, 6 minutes charging tme for single cell, 10~20 minutes charging time for electric vehicles packs. 5. Wide Temperature Range: Stable and reliable performance covering the wide temperature range from -50 ℃ to 60 ℃. Work in super cold climate that no others can compete with.
ITEM
VALUE
Nominal Voltage
2.3V
Rated Capacity
40Ah
High Rated Capacity (240A at 25℃, constant current)
37Ah
Rated Power (40A at 25℃, constant current)
88Wh
Energy Density
161Wh/L
Maxium Charge/Discharge Current
10C (400A)
Internal resistance
<1mΩ
Dimensions
(DIA)66 mm *(H)160 mm
Weight
1.23kg
Company Information
Certificate Display
FAQ
1)When Can I get the price? We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, Pls call us or tell us in your email so that we will regard your inquiry priority
2)How can I get a sample to check your quality? After price confirmation, you can require for samples to check our quality. If you just need a blank sample to check the design and paper quality, we will provide you sample for free, as long as you afford the express freight
3) How long can I expect to get the sample? After you pay the sample charge and send us Confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays You can use your own express account or prepay us if you do not have an account
4) How long does the whole procedure being worked out? After you place a order, the production handling time is bout 25-30 days We need 7 days to prepare all the stuff then 30 days for manufacturing
5)What about the transportation and delivery date? Normally we use shipment to transport the goods. It is about 25-40 days. It also depends on which country and port you are. It could be shorter if you need to send the goods like Asian If there are some emergencies we can send the goods via air express, as long as you afford the traffic expense
6)How to payment for order? Contact sales person and ask Pl for your payment, the account should be listed in Pl, That is our company account
Contact us now if you have any questions and we will reply you soon!
