Sungraf Oil Drilling Additive Resilient Graphite Powder
- Category: Graphite Powder >>>
- Supplier: Qingdao Matery Graphite Co. Ltd.
Share on (62503773983):
Product Overview
Description
RESILIENT GRAPHITE
| product name | Graphite Powder |
| type | Natural |
| fineness | 100-800μm |
Graphite is a coarse-sized plugging agent used in water, oil or synthetic-based drilling fluids to bridge and seal permeable and fractured formations. When drilling depleted zones exposed to high different pressures, the bridging and plugging capabilities of GRAPHITE additive can reduce the potential for stuck pipe. Graphite is chemically inert and thermally stable, and will not affect rheological properties when used at recommended concentrations. It can lower the potential for lost circulation and reduce torque and drag in many drilling applications.
Typical Physical Properties
Physical appearance:Black powder
Specific gravity: 2.19-2.26
Application
Graphite additive is designed to be used in any type of drilling fluid to bridge and seal permeable fractured formations, thus controlling lost circulation and reducing the possibility of differential sticking. Graphite can also be used to decreases the coefficient of friction (CoF) of drilling fluids. The recommended treatment for seepage losses (<10 bbl/hr or 1.6 m3/hr) is 15 to 20lb/bbl (43 to 57 kg/m3) in spotted pills or sweeps. The recommended treatment for partial losses (10 to 100 bbl/h or 1.6 to 16 m3/hr) is 20 to 50 lb/bbl (57 to 143 kg/m3) in spotted pills.
Graphite may require additional wetting agent when used in an oil-or synthetic-based mud system.
Advantages
• Effective bridging and sealing agent for a wide range of formations severity of losses.
• Controls seepage losses, thereby reducing the possibility of differential sticking.
• Decreases the CoF to reduce torque and drag in all mud systems.
• Temperature stable to more than 260o C (500oF).
• May be used in combination with other additives, particularly lost circulation materials.
Packing and Storage
GRAPHITE is packaged in a 25 kg (55.1 lb), multi-wall paper sack.
Store at moderate temperatures in a well-ventilated and dry area
Company Information
Located in Qingdao where has rich graphite mineral resources, Shandong Sungraf Carbons Co., Ltd. started in 2008 and has focused on Graphite and Carbon Products all the time. Now we are bocoming more and more professional, reliable and trustworthy. Our products have been exported to many countries and earned good market reputation.
We remain a major supplier of Flake Graphite, Expandable Graphite, Micronized Graphite, Synthetic Graphite, Carbon and Graphite Products and a variety of other raw materials. By excellent production and testing equipment, quality guarantee system measure and long term technology innovation, we could offer the most reliable products and the highest-quality-service to customers.
Certifications
FAQ
Q1. How could I get a quick quotation?
Firstly, a drawing or detailed explanation of graphite dimensions.
Secondly, graphite material technical specifications, or alternatively applications of your required graphite products and your order quantity.
Q2. What is your terms of packing and loading?
Packing: 25-kg-water-proof bags or 1-tonne bags
Loading: 20 tonnes per 20-foot container.
Q3. What is your terms of payment?
T/T 30% as deposit, and 70% before delivery, LC at sight.
Q4. How about your Delivery time/ Lead time?
Generally, it will take 7 to 20 days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
Q5. Can you offer samples for our reference?
Of course. Samples are FREE, but you have to pay the courier cost.
