Rolwal MIG 500PF External 15kgs wire feeder IGBT Module 500AmpMIG/MAG/MMA Co2 Gas shielded Aluminum Brass Plate Welding Machine

Product Overview

Description

MAIN FEATURES:



1.Led display,welding data can be accurate preset parameters.



2.Adopt with big power IGBT module,current mode control,high reliability and stability.



3.Closed loop feedback,constant voltage,strong ability to res

ist the voltage fluctuation.



4.Compact,solid,tolerance stamping collision.



5.MMA and Carbon arc air gouging function,mutil-function.



6.Reactor control,stable welding process,small splash,deep bath,smooth welding furface.



7.ARC start slow wire feed,after welding cutting the boll,ensure the successful rate of Arc start.



8.Suitable for thickness>0.8mm plate welding.



9.4pcs wheel drive wire feeder machine,15kgs wire feeder machine,Co2 heater,high quality MIG torch

  Technology Data

Model	MIG-400PF	MIG-500PF
Rated Input Voltage(V)	380	380
No-load Voltage(V)	70	70
Current Range(A)	50-400	50-500
Rated Duty Cycle (%)	60	60
Input Capacity (KVA)	17	24.5
Class Of Insulation	F	F
Applied WeldingRod(mm)	0.8-1.6	0.8-1.6
Weight(kg)	42	42
Packing Dimension(mm)	720X430X610	720X430X610
