Model | unit | FA-03 | ||
Rated heating capacity | KW | 11 | ||
BTU | 37543 | |||
Hot water supply | T/h | 0.23 | ||
Average heating input power | KW | 2.34 | ||
Rated heating input current | A | 11.2(220V) | ||
6.5(380V) | ||||
Max outlet water temp | ℃ | 60℃ | ||
COP | 4.62 | |||
Power | V/Hz | 220-240V/380-415V/50HZ | ||
Nosie | dB(A) | 50 | ||
Dimension | Width | mm | 1100 | |
Deepth | mm | 460 | ||
Height | mm | 687 | ||
Unit weight | KG | 120 | ||
Throttling type | Electronic expansion valves | |||
Refrigerant | R410A | |||
Working air temp range | – 20℃~45℃ | |||
Compressor | Type | Scroll Copeland,.hitachi,panasonic | ||
Security functions | Built-in protection device overheating protection, sequence protection, undervoltage protection, delay protect | |||
Air source heat exchanger | Type | Finned heat exchange | ||
Qty | piece | 1 | ||
Fan type | Axial big twist Angle fan | |||
Motor power | W | 50 | ||
Hot water side heat exchange | Type | tube in shell heat exchanger/plate heat exchanger | ||
Water flow | m3/H | 1.86 | ||
Water pressure down | kPa | 27 | ||
Pipe size | Inch | 3/4 | ||
Water side max working pressure | kPa | 1000 |
Remarks:the test conditions of above parameter:dry bulb temp is 20℃.wet buld temp is 17℃.inlet water temp is 15℃.outlet water temp is 60℃
