high precision flat bed horizontal GSK Siemens control CAK6161 cnc lathe machine torno price for sale
- Category: >>>
- Supplier: Zaozhuang Luxing Machine Tool Co. Ltd.
Share on (62505048180):
Product Overview
Description
high precision flat bed horizontal GSK Siemens control CAK6161 cnc lathe machine torno price for sale
Product Description
Application :
CAK series CNC lathe machine is an economical ,practical type machine tools iwth good quality .
The machine has a very wide use which is suitable or internal and external turning ,tapering,circular arc ,thread ,boring ,reaming of axle and disk workpiece .It also can achieve non-circular curve machining ,You can choose the CNC system and optional accessories according to your requirement .
Product main technical specifications:
Specifications | Units | CAK6140 CAK6140B CAK6140C | CAK6150 CAK6150B CAK6150C | CAK6161 CAK6161B CAK6161C | CAK6166 CAK6166B CAK6166C | CAK6180 CAK6180B CAK6180C | ||
Max.swing over bed | mm | 400 | 500 | 610 | 660 | 800 | ||
Max.processing length | mm | 750/1000/1500/2000/3000 | ||||||
Spindle taper |
| MT6(Ø90 1:20 for B)[Ø113 1:20 for C] | ||||||
Chuck size | mm | C6(D8)[D8] | ||||||
Spindle bore | mm | 52(80 for B)[105 for C] | ||||||
Spindle speed 3 steps (auto change gear) | rpm | Independent spindle:100-1600 21-1500(162-1500,66-500,21-150) | ||||||
Tailstock sleeve travel | mm | 150 | ||||||
Tailstock sleeve taper |
| MT5 | ||||||
Position accuracy | mm | ±0.015 | ||||||
Repositioning accuracy | mm | ±0.006 | ||||||
X/Z axis rapid traverse | m/min | 4/6 | ||||||
Spindle motor | kw | 7.5 | 11 | |||||
Machine dimension for 750 | mm | 2550x1550x1700 | 2550x1550x1900 | |||||
Machine dimension for 1000 | mm | 2750x1550x1700 | 2750x1550x1900 | |||||
Machine dimension for 1500 | mm | 3250x1550x1700 | 3250x1550x1900 | |||||
Machine dimension for 2000 | mm | 3700x1550x1700 | 3700x1550x1900 | |||||
Machine dimension for 3000 | mm | 4710x1550x1700 | 4710x1550x1900 | |||||
Machine weight for 750 | kg | 2100/2800 | 2120/2900 | 2250/2850 | 2300/2900 | 2400/3000 | ||
Machine weight for 1000 | kg | 2200/2900 | 2240/3000 | 2400/3000 | 2450/3050 | 2550/3150 | ||
Machine weight for 1500 | kg | 2300/3150 | 2350/3200 | 2600/3200 | 2650/3250 | 2750/3350 | ||
Machine weight for 2000 | kg | 2700/3350 | 2740/3400 | 2830/3400 | 2880/3450 | 2980/3550 | ||
Machine weight for 3000 | kg | 3500/4100 | 3600/4200 | 3650/4250 | 3700/4300 | 3800/4400 | ||
Details:
FAQ
1:How can I choose the most suitable machines?
A: Please tell me your specifications (or send your workpiece drawing to us) ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in CNC Lathe Machine ,CNC Milling Machine ,CNC Machining Center ,Lathe Machines ,turret milling machine,drilling milling machine,universal milling machine,Drilling Machine ,Radial Drilling Machine ,Band Saw Machine ,Shaper machine,Surface grinder,slotting machine and so on .
3: How long is the delivery time?
For standard machines,it would be around 30 days;For non-standard machines and customized machine according to client’s specifications requirements,it wouble be a little longer.
4.Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277599 China.
You are warmly welcomed to visit us.
5. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
6: What's the Payment Terms?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
7: What's the MOQ?
A: 1 set .
