chocolate candy tablet film coating machine chocolate tempering and enrobing machine
MY WHATSAPP: +86 13525551927
Product Description
1.This machine is mainly used for making pellet, film coating on tablets. It can also be used for making ball shape products or granules, mixing, and polishing, etc.Such as:chocolate polishing, peanut coating, sugar coating,seasoning, producing tapioca pearls, and pelletizing the desiccant & aluminium hydroxide, porcelain ball making, etc.
2.This machine consist of main body, worm wheel box, coating pan, heating device,hot air&common blower,electrical equipment, etc. The transmission process that the motor drive the worm wheel and worm via triangle belt to make the coating pan rotate.Then the material revolve up and down in the coating pan, so that even mixing, pelletizing and polishing can be completed well.
Tablet coating machine detail Information
Model
HC-PC300
HC-PC400
HC-PC600
HC-PC800
HC-PC1000
Capacity
1-3kg/cycle
2-5kg/cycle
8-15kg/cycle
30-50kg/cycle
50-70kg/cycle
Pot inclination
42°
42°
30°
30°
30°
Motor Power
0.37kw
0.37kw
0.75kw
1.1kw
1.5kw
Blower Power
60w
60w
100w
200w
200w
Pot Volume
1L
1L
5L
8L
10L
Heating Power
1.4KW
1.4KW
2KW
3KW
4KW
Weight
49KG
50KG
150KG
280KG
300KG
Rotational Speed
0-46r/min
0-46r/min
0-40r/min
0-32r/min
0-32r/min
(Don't Worry! We have several Models. We can recommend you according to your requirement. Just Tell Us: Capacity, Filling machine and Capsule Size.) Contact us>>
Pill coating machine Working principle.
In order to make the chip evenly coated crystal as soon as possible on the surface, and to achieve the objective of polishing, it must be with a manually operation to spray compound syrup and mixing element to the pot repeatedly recurringly. Sugar coated tablets roll in the pot through the clockwise of pot, the tablets are uniformly distributed in the whole chip, and then make the hot air to the pot to remove surface moisture of the tablet, get a qualified sugar coated chip finally.
The machine can provide the best pot for the coating process, it can It is in a stable line speed to ensure the best logistics in the form of tablets curve, to meet process requirements which are the thickness of coating uniformly, bright color, no pitting.
