Casun OEM Gear motor 24V20W DC brushed Brake motor GPG 05SC 3GN 40K aisle gate motor
- Category: >>>
- Supplier: Guangzhou Fude Electronic Technology Co. Ltd.
Share on (62507822758):
Product Overview
Description
Application: Aisle gate motor, used for wing gate, swing gate, pedestrian automatic door, etc.
parameter:
Voltage: 24V
Current: 1.39A
Power: 20W
Motor speed: 1800 rpm (before deceleration)
Motor torque: 1.08 KG.CM (before deceleration)
Installation size: 70 * 70
Shaft diameter: 10 mm
Reduction ratio: 3GN-40K
SPECIFICATION:
MOTOR FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | ||
MOTOR TYPE | Dc brushed type / dc brushless type | ||
Motor speed | 450 rpm - 10000 rpm ( can be suctomized) normal speed is 1500/1800/2500/3000 rpm | ||
OUTPUT POWER | 6W / 10W / 15W / 25W / 40W / 60W / 90W / 120 W /150W / 180W / 250W ......1000W(can be customized) | ||
OUTPUT SHAFT | 8mm / 10mm / 12mm / 15mm ; round shaft, D-cut shaft, keyway shaft (can be customized) | ||
Voltage type | 12V / 24V / 36V / 48V / 90V / 110V /220V | ||
Accessories | electromagnetic brake / encoder | ||
| |||
GEARBOX FRAME SIZE | 60 mm / 70mm / 80mm / 90mm / 104mm | ||
GEAR RATIO | MINIMUM 3:1---------------MAXIMUM 750:1 | ||
GEARBOX TYPE | PARALLEL SHAFT GEARBOX AND STRENGTH TYPE | ||
Right angle hollow worm shaft | Right angle spiral bevel hollow shaft | L type hollow shaft | |
Righjt amgle solid worm shaft | Right angle spiral bevel solid shaft | L type solid shaft | |
K2 series airtightness improved type | |||
Certification | CCC CE UL RoHS | ||
