Wholesale Fangling F2500B FLSK 2500B CNC Controller for CNC Plasma Cutting Machine

Product Overview

Description



Model: FLSK-2500B

Brand:Fangling

CNC controller used for CNC plasma cutting machine.







1.Specifications:





Monitor	10.4 inch 800*480, high definition 16 million colors and high brightness LCD
Memory	64M SDRAM
Program space available for user	256M electronic hard disk
System master frequency	400MHz
USB	USB 1.1 front interface, at least 16GB U disk supportable
Keyboard	electronic PCB foil keyboard
Chassis	full-steel structure completely shielded which defends electromagnetic radiation, interference and static electricity







System information:



1.45 categories different graphics (including grid pattern), chip part and hole part are alternative.

2.Graphics have some operations such as Proportion, Rotate, Mirror.

3.Graphics can be arrayed in matrix, interaction, stacked modes.

4.According to plate thickness, the cutting speed is automatically restricted by a speed limit in the corner, effectively preventing over burn.

5.Metric system/ imperia system switch.

6.Steel plate can be adjusted according to any steel side.

7.Coordinate system can be customized to support the two-dimensional coordinates of all eight kinds.

8.All input and output port type and the number can be customized (normally open or normally closed)



9.System and parameters backup, update system online.

10.Chinese / English (including Japanese, Russian, French and other languages )file system and menu can be switched only by one key.

11.Select row and column manually.

12.Support edge cutting and offset cutting.

13.Automatically memorize the working situation and the last cutting point when power off.

14.Dynamic/static illustration of the process, graphics zoom in / out, dynamically tracking cut-off point under zooming state.

15.Support artgrave, TYPEIII, PM2000 cam software

16.Set up different administration authority to and the corresponding password to safeguard the interests of managers.



FAQ:

Q1:When the machine can’t work well,What should I do?

A1.(1)Salesman is online for 24-hours, they can check the problems with engineer and then give you solutions as soon as possible.

     (2)Our machine is with one’s year warranty, If any problems of machine parts under “normal use”,new machine parts will be sent by air in free.

     (3)Please rest assured that operation CD and manual will be offered along with machine,making you can operate the machine easily.

Q2:What’s kind of payment way ?
A2.T/T ,Paypal,Western Union or Trade assurance order in alibaba.

Q3:Can you produce the product according to customers' request?
A3.Sure ,we are the professional manufacturer,just give us the drawing or request for customized.
