Ground carbide rods length 100mm looking for buyers who demand

Product Overview

Description

Ground carbide rods length 100mm from zcc







Application of  Carbide rods and bars

We supply premium grade tungsten carbide rod from stock in unground, centerless ground and polished form.
Recommended Grade for tungsten carbide rod: YG6, YG8, YG6X, YG012, YG013, YG8A etc
Tungsten carbide rod applications include drill bits, end mills, and reamers. Custom diameters and length are also available in these grades as well as metric sizes.



Specification of  Carbide rods and bars

GRADE		YL06C	YL10.2	YL10A	YF06	XF20S	XF30S	XT30S	XU30	XU09S	XU10W
Drilling		*	*	*	*	*
Milling		*	*	*		*	*	*	*	*	*
Reaming					*
P	General carbon steel		^		#	^	^		#
M	Stainless steel					#		^
K	Cast Iron		^	#		^	^		#
S	Ti					#		^
	HRSA						#
N	Al-Mg		^	#	^	^	^		#
H	Hard steel									^
Others	Plastic		#			#
	CFRP	^(coated)
	Wood					^	#				^
	Ceramic	^(coated)

Carbide ground Rod(tol.h5/h6)	,
Length100mm ,
Chamfered 45°
Type	D(mm)	L(mm)	ToleranceL(mm)	C(mm)
φ1.0×100	1.0	100	up on request	0.3
φ1.5×100	1.5	100	up on request	0.3
φ2.0×100	2.0	100	up on request	0.3
φ2.5×100	2.5	100	up on request	0.3
φ3.0×100	3.0	100	up on request	0.3
φ3.5×100	3.5	100	up on request	0.3
φ4.0×100	4.0	100	up on request	0.3
φ4.5×100	4.5	100	up on request	0.3
φ5.0×100	5.0	100	up on request	0.3
φ5.5×100	5.5	100	up on request	0.3
φ6×100	6.0	100	up on request	0.5
φ6.5×100	6.5	100	up on request	0.5
φ7.0×100	7.0	100	up on request	0.5
φ7.5×100	7.5	100	up on request	0.5
φ8.0×100	8.0	100	up on request	0.5
φ8.5×100	8.5	100	up on request	0.5
φ9.0×100	9.0	100	up on request	0.5
φ9.5×100	9.5	100	up on request	0.5
φ10.0×100	10.0	100	up on request	0.5
φ10.5×100	10.5	100	up on request	0.5
φ11.0×100	11.0	100	up on request	0.5
φ11.5×100	11.5	100	up on request	0.5
φ12.0×100	12.0	100	up on request	0.7
φ13.0×100	13.0	100	up on request	0.7
φ14.0×100	14.0	100	up on request	0.7
φ15.0×100	15.0	100	up on request	0.7
φ16.0×100	16.0	100	up on request	0.7
φ18.0×100	18.0	100	up on request	1
φ19.0×100	19.0	100	up on request	1
φ20.0×100	20.0	100	up on request	1
φ21.0×100	21.0	100	up on request	1
φ22.0×100	22.0	100	up on request	1
φ23.0×100	23.0	100	up on request	1
φ24.0×100	24.0	100	up on request	1
φ25.0×100	25.0	100	up on request	1.5
φ26.0×100	26.0	100	up on request	1.5
φ28.0×100	28.0	100	up on request	1.5
φ30.0×100	30.0	100	up on request	1.5
φ32.0×100	32.0	100	up on request	1.5
φ33.0×100	33.0	100	up on request	1.5
φ34.0×100	34.0	100	up on request	1.5
φ35.0×100	35.0	100	up on request	1.5
φ36.0×100	36.0	100	up on request	1.5
φ38.0×100	38.0	100	up on request	1.5
φ40.0×100	40.0	100	up on request	1.5





We are a manufacturer company,specialized in follwing products series:

1.Rare metal powders

2.Hard materials

3.Drilling&Exploiting for mines&oil Fields
4.Tungsten&molybdenum products

5.Tantalum&niobium products

6.Metal-cutting tools
