9mm PCb mount vertical potentiometer with push rotary switch

Product Overview

Description

9mm PCb mount vertical potentiometer with push rotary switch



9mm single gang linear type single lap digital potentiometer with metal shaft Highest working Voltage:B taper 50V AC other taper 25V AC traveling noise: 100mv Rotational torque:10~200gf.cm Total Rotational angle:300°±10° Rotation stop strength:3Kgf.cm shaft strength:8Kgf max. shaft shaking:0.6×L/20mm p-p max. Resistance tolerance:±20% resistance residue:R≤10KΩ 10Ω;10K<R<250KΩ 20Ω;R≥250K 0.1% max. of total resistance Power:B taper 0.05W other taper 0.025W Insulation resistance:100MΩ min. at 250V DC Voltage resistance:1 minute at 300V
