KR800C/800S copper wire granulation machine with the pre-shredder is highly recommend to process the thick cables like the Heavy industrial wires, bulky cables, cable mixture with iron scraps, etc.The heavy industrial cables and the bulky cables can not be processed by copper wire granulation machine directly due to the over size. By equipping the pre shredder, the size can be reduced to fit with the granulation machine.
Also, most of the cables contain iron components like the nails and clips, those iron components can damage the the blades of the granulation machine if they are fed directly to the granulation machine. To disassemble those components by manually will increase the labor cost. By equipping a suspend type iron remover, the iron components can be automatically removed, then the usage life of the blades can be effectively increased.
Application: House lighting wires, Ethernet(Cat 5/6) cables,heavy-duty cable(single core), heavy industrial cables, telecom cables, single core aluminum cables.etc,
Range:Multiple size cable process-able (0.5-30mm)
Model
Size
Power
Weight
Capacity
KR400C
2600*1600*2100mm
22kw
1200kg
80-100kg/h
KR600C/S
3900*1900*2300mm
40.5kw
3200kg
300-500kg/h
KR800C/S
8000*1900*2400mm
76kw
6000kg
600-800kg/h
Detailed Images
Related Products
Packing&Shipping
All of the goods will be packaged with the PE film and fixed by SELF-LOCKING NYLON CABLE TIES
After Sales Service
Warranty
100% brand new when leaving the factory. we guarantee quality of the machines for a period of one year from the date of a trial run to the finish, but not to exceed thirteen months from the date of which machines away to the delivery port. If any parts (excluding easily damaging parts) are found defective in quality in the first year, the seller should replace free-of-cost. After one year, parts can be replaced on favorable payment basis.
Company Introduction
Established in 1998, Gongyi City Kerui Machinery Factory Co., ltd. is a professional manufacturer and exporter that is concerned with the design, development and production of waste management equipment as copper wire recycling machine, scrap motor recycling machine, aluminum scrap recycling machine,etc.
Our Services & Strength
With the strong research and development team, our company is able to provide the customized service for each of our customers. 1.With the 3D layout according to the real working condition of our customer site, it can help the worker to expedite the progress of installation. 2.With the years of exporting experience, we can also provide the installation&use package(tools, wiring, spare parts,etc.) to reduce the local working cost. 3.With the fully English technical support team, our technical can directly communicate with our customer to guarantee the service quick, accurate and effective.
FAQ
Q:What is the capacity of the KR800C copper wire granulator?
A:The capacity of the machine is effected by three items as the tickness of the cables, the copper content of the cables and the length of the cables.
For example:
To process the house lighting wires with copper content 40% without pre chopping, the capacity of the KR800C copper wire granulator can achieve 800kg/h.
Q:What is the power of the main motor?
A:The power of the main motor is 55 kw and we could also upgrate to 75kw if you are going to process the heavy duty industrail cables.
Q:What is the total power of the KR800S granulator?
A:The total power of the machine is 76kw and it requires the transformer with capacity 300KVA(3phase 380-440V)
