230V AC , 115V AC, 24V DC/AC, 12V DC/AC ( Please the label on the detector for more information)
Voltage tolerance AC
+10% / -15%
Voltage tolerance DC
±15%
Power Consumption
4.5VA
Output relays
240V/5A
Operating temperature
-20°C to +65°C
Storage temperature
-40°C to +85°C
Frequency range
20 kHz to 170 kHz
Reaction time
10ms
Signal holding time
Unlimited / limited when loop is permanently covered 10 minutes
Sensitivity
Adjustable in 4 increments
Loop inductance
Total loop plus connection wiring: 50μH to 1000μH.
Ideal is 100μH to 300μH
Loop connection wiring
Max. length 20 meters, twisted at least 20 times per meter
Size of Housing
78x40x108 mm (L x W x H)
Packing & Delivery
50pcs/Carton, 44*26*26cm (L*W*H)
Company Profie
Production process
FAQ
The detector must be installed in a convenient weatherproof location as close to the loop as possible. Installation location must choose to stay away from the heat source, it around other devices must maintain a distance of at least 10mm (mustn’t fix cling to the cabinet). A correct loop configuration and detector installation will ensure a successful inductive loop detection system. Loop of several important parameters include: loop figure, size, and turns, install methods (details as “Loop installation guide”).
