Rebar Scanner LANGRY LR G200 Touch Screen Integrated Rebar Detector Steel Bar Scanning Rebar locator
- Category: Industrial Metal Detectors >>>
- Supplier: Jinan,Langrui,Detection,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
LR-G200 Touch screen integrated rebar detector
Standards:
DIN 488
ASTM A 615/A 615M-01b
CAN/CSA-G30,18-M92
GB 50012-2002
Introduction
LR-G200 integrated rebar detector is a portable intelligent NDT device, which is mainly used for structural testing of reinforced concrete, and able to carry out accurate testing on thickness of rebar cover and diameter of rebar on the surface of reinforced concrete, and analyze distribution of rebar.
Functions and characteristics
1. The instrument sensor is of integrated structure small SIZE, thus permitting easy operation.
2. Carry out testing with combination of high-power transmitting coil and multiple small coil to ensure higher accuracy and resolution.
3. Perform displacement scanning and rebar distance measurement at a higher accuracy level with use of high-accuracy grating sensor.
4. Provide different types of scanning to suit the different measurement cases.
5. Permit large and small-range testing, with the scanning distance up to 65m max. Perform data testing in a flexible way. The instrument itself allows storage of max. 4000 components.
6. Permit correction of multiple stirrup so as to obtain more accurate testing results.
7. Furthermore, the USB wire data transmission and Bluetooth wireless data transmission are allowed so that the quick data uploading is possible.
8. Use 3.2” 65K color LCD screen to yield the higher resolution and better display, plus the capacitive touch screen, thus facilitating the man-machine interaction.
9. Perform power supply with use of 8.4v 3200mah high capacity lithium-ion battery to ensure that the instrument can continuously operate around-the-clock.
Technical indicators
Description | Technical indicators | |
Applicable range of rebar diameter(mm) | Φ6-Φ50 | |
Max. range (mm) | 1st range | 2~100 |
2nd range | 2~200 | |
Max. allowable deviation on thickness of protective layer | ±1(mm) | 2~80 |
±2(mm) | 81~120 | |
±3(mm) | 121~160 | |
±4(mm) | 161-200 | |
Applicable range on diameter estimate (mm) | Φ6-Φ50 | |
Max. deviation on diameter estimate | ±1 spec | |
Display accuracy on diameter estimate (mm) | 0.1 | |
Performance indicators on LR-G200 integrated rebar detector | |||||||
Quick scanning | Fine scanning | Profile scanning | Grid scanning | image scanning | 3-D imaging | Range of scanning | Mode of data transmission |
Yes | Yes | Yes | Yes | Yes | Yes | Unbounded | Bluetooth or USB |
Data correction | Way of power supply | Instrument weight | Screen size | Laser positioning | Touch screen operation | Screen lattice | Instrument size |
Yes | Lithium battery | 1KG | 3.2” | 3-wire | Yes | 320x240 | 235x120x130 |
The rebar detection function is designed for detect on thickness of rebar protective layer, rebar location, rebar diameter and distribution. Moreover, the obtained testing data can be saved to facilitate data view or uploading after detection.
Supported scan mode;quick scan, profile scan,fine scan,grid scan,image scan,3Dimaging
software
The rebar detection data analysis software is a multi-function analysis software developed by Jinan Langrui Detection Technology Co., Ltd. for processing the rebar detection data. The software can run in XP/win7/win10 OS, presenting friendly interface and easy operation, which is specifically designed for project detection staff.
1) Conduct management on all component information as well as the detection data at each measuring point;
2) Conduct analysis and evaluation on detection data according to the construction quality acceptance criteria;
3) Display the component data in a graphic way;
4) Generate a detection data file through integration of several ones; it is easy to add or remove the detection data;
5) Print the preview and export treatment results;
6) It is easy to import the rebar scanner data into the computer with use of the software to facilitate further analysis and archive;
7) Automatically generate the detection report in word format.
The data files saved in the software has the file extension name in . xgjy format. The detection report automatically generated has the file extension name in .docx format.
