China 86MM wide 780W High power BLDC motor 3000PM 310V Permanent Magnet brushless dc motor with 220V controller kit

Product Overview

Description

China 86MM wide 780W High power BLDC motor 3000PM 310V Permanent Magnet brushless dc motor with 220V controller kit



Note: the motor with magnetic ,so magnetic inspection fee will be incurred during transportation. Please contact shop assistant to supplement it.large quantities can dispense with it



KeyWords	Brushless DC Motor
Number of poles	4P
Rated Voltage	310V
No Load Speed	3600±10%
No load current (Max)	0.4A
Rated Speed	3000±10%
Rated Torque	2.5NM
Rated power	785W
Rated Current (Max)	3.3A
Peak Torque	7.5NM
Torque constant	0.138NM/A
Back EMF	62V/krpm
Rotor inertia	320kg.mm2
Body length	130mm
Mass	4.3Kg
