WZUMER APG Тип биметаллический медный алюминиевый провод, соединительный параллельный паз, PG Зажим соединитель

Material

High strength aluminium alloy by forging.

Product Property:

APG is used for connecting of branching AAC,AAAC or ACSR overhead conductors. Forging creates a high strength clamp. Slotted holes
allow adjustment for varying conductors on each side. Its type test is in accordance with IEC61238-1.

APG-A1

Al 16-70

1×M8×40

APG-A2

Al 16-150

1×M8×45

APG-B1

Al 16-35

2×M6×35

APG-B2

Al 16-70

2×M8×45

APG-B3

Al 16-150

2×M8×50

APG-B4

Al 25-185

2×M10×60

APG-C1

Al 16-70

3×M8×45

APG-C2

Al 16-150

3×M8×50

APG-C3

Al 25-240

3×M10×60

APG-C4

Al 35-300

3×M10×70
