China Hight Quality Conventional Lathe Machine Price
US $3850-$4520
Высокоточный фрезерный сверлильный комбинированный токарный станок JYP290VF
- Category: Manual Lathe >>>
- Supplier: Chizhou Syntop CNC Industrial Co. Ltd.
Share on (62517619329):
Product Overview
Description
Product Description
Features
Supersonic frequency hardened bed way.
Spindle speed readout.
Variable Speed.
Precision roller bearing for spindle.
High quality steel, ground and hardened gear inside headstock.
Various threads cutting function available.
Specifications for JYP290VF | ||||
Turning | Distance Between Centers | 700mm | ||
Swing Over Bed | 280mm | |||
Taper Of Spindle Bore | MT5 | |||
Spindle Bore | 38mm | |||
Taper Of Tailstock Quill | MT3 | |||
Range of Metric Thread | 0.2-3.5mm | |||
Range of Inch Thread | 8-56 T.P.I | |||
Cross Slide Travel | 140mm | |||
Spindle Speed | 50-1800RPM | |||
Width of bed | 180mm | |||
Tailstock quill travel | 94mm | |||
Vol./Freq | As custoner's requirement | |||
Motor | 1100W DC motor/ 850W AC motor | |||
Drilling and Milling | Drilling Capacity | 20mm | ||
Face Milling Capacity | 63mm | |||
End Milling Capacity | 16mm | |||
Spindle Travel | 50mm | |||
T-slot Size | 10mm | |||
Spindle Speed | 50-2250 RPM | |||
Motor | 750W | |||
Net Weight | 280kgs | |||
Gross Weight | 321kgs | |||
Packing Size | 1400×750×1010mm | |||
