High Performance Microplate Washer Reader With 7 Inch Touch Screen and blood testing equipments

Product Overview

Description



2.1  Device Mode
HBS-1101
2.2  Device Name
Microplate Reader
2.3  Features of Microplate Reader
2.3.1 Facility Management Type:	II
2.3.2 Pollution Level:	Level 2
2.4  Input Power:	60VA
2.5  Normal Working Conditions:
2.5.1  Power adapter: INPUT:	AC100-240V, 50/60Hz   OUTPUT: DC12V 5A
2.5.2  Environmental temperature:	5℃-40℃
2.5.3  Relative humidity:	when the temperature is lower than 31℃, the max. relative humidity is 80%; when the temperature us 40℃, the relative humidity declines to 50%.
2.5.4  Atmosphere pressure:	86 kPa - 106kPa
2.5.5  Working position: horizontal
2.5.6  Working times: 8 hours continuously
2.5.7  Working times: 8 hours of continuous intense light interference.
2.6 Transportation and Storage Conditions
2.6.1	Environmental Temperature: -20℃-55℃
2.6.2	Relative humidity: ≤95%
2.6.3	Atmosphere pressure: 86 kPa-106kPa
2.6.4	Under such transportation and storage conditions, before electric connection and use, the device should be put under the normal working conditions for 24 hours.
2.7  Main Technical Data
2.7.1  Scope of readings:	8 vertical channels
2.7.2  Wavelength range:	400 - 999nm
2.7.3  Spectral filter:	405, 450, 492, 630nm and other regular wavelength
2.7.4  Scope of readings:	0.000 - 4.000Abs
2.7.5  Linear Range:	0.000 -  3.000Abs
2.7.6  Repeatability:	CV≤0.3%
2.7.7  Stability:	drift ≤±0.003A
2.7.8  Function of vibration plate:	3 options available for vibration plate strength (from weak to strong), vibration time is adjustable from 0s to 255s.(error range: ±2s)
2.7.9   Wavelength indication error:	≤±2nm
2.7.10  Wavelength repeatability:	≤±1.5nm
2.7.11  Absorbance indication error:	≤±0.01Abs
2.7.12  Sensitivity:	≥0.01 L/mg
2.7.13  Channel difference:	≤0.03Abs.
2.8  Composition
A Microplate reader is composed of optical system,LCD screen, touch screen,micro-computer system,chassis, computer(optional),printer(optional) and other components.
2.9  Device dimension:	about 400×255×220(mm)
2.10  Device weight:	about 6kg
2.11 Device Outline Diagram
