IST 30KVA Three 3 phase Isolation Transformer 30KVA step up down Transformer 110/120V/200V/220V/230V/240V etc. optional
- Category: >>>
- Supplier: Nanjing Conpo Power Tech. Co. Ltd.
Share on (62519573172):
Product Overview
Description
Single phase / Three phase Isolation Transformer step up and down Transformer 110V/120V/220V/230V/380V/400V/415VAC optional
isolation transformer 240v / isolation transformer 100KVA / isolation transformers 380V / 3 phase isolation transformer / isolation transformer 10kva / isolation transformer 160kva / isolation transformer 1000va / step up transformer 120V to 240V
1. Feature
The Ultra-Isolation & Noise Suppression Transformer are indoor air self cooling ones, which is available in the circuit of AC 50Hz and voltage less than 1000V. Input/output voltage of all transformers can be made according to order. Number of phase has three-phase and single-phase or three-phase input with single-phase/two-phase output etc. The max. Rated power will be up to 1000kVA.
2. Main Technical Data for Single phase Isolation transformer
Phase no.: Single phase
Input voltage: 110V/120V/200V/220V/230V/250V etc. optional
Output voltage: 110V/120V/200V/220V/230V/250V etc. optional
Frequency: 50Hz-60Hz
Ambient temperature: -10 º C~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min
Insulation resistance: > 2MΩ
The Ultra-Isolation & Noise Suppression Transformer are indoor air self cooling ones, which is available in the circuit of AC 50Hz and voltage less than 1000V. Input/output voltage of all transformers can be made according to order. Number of phase has three-phase and single-phase or three-phase input with single-phase/two-phase output etc. The max. Rated power will be up to 1000kVA.
2. Main Technical Data for Single phase Isolation transformer
Phase no.: Single phase
Input voltage: 110V/120V/200V/220V/230V/250V etc. optional
Output voltage: 110V/120V/200V/220V/230V/250V etc. optional
Frequency: 50Hz-60Hz
Ambient temperature: -10 º C~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min
Insulation resistance: > 2MΩ
3. Main Technical Data for Three phase Isolation transformer
Phase no.: Three phase
Input voltage: 200V/220V/230V/240V/360V/380V/400V/415V etc. optional
Output voltage: 200V/220V/230V/240V/360V/380V/400V/415V etc. optional
Frequency: 50Hz/60Hz
Ambient temperature: -10 º C~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min
Insulation resistance: > 2MΩ
3. Application
It is available in the electric supplying of electronic instruments, machinery equipment, lighting, rectifying device etc.
Phase no.: Three phase
Input voltage: 200V/220V/230V/240V/360V/380V/400V/415V etc. optional
Output voltage: 200V/220V/230V/240V/360V/380V/400V/415V etc. optional
Frequency: 50Hz/60Hz
Ambient temperature: -10 º C~+40º C
Relative humidity: <95%
Temperature rise: < 60 º C
Withstand voltage: 1500V/min
Insulation resistance: > 2MΩ
3. Application
It is available in the electric supplying of electronic instruments, machinery equipment, lighting, rectifying device etc.
4. Model
Model | Rated capacity | Phase | Frequency | Input Voltage | Output Voltage |
IS-1KVA | 1KVA | 1P/1P | 50/60Hz | 110V, 120V, 200V, 220V, 230V, 240V, 250V etc. optional | 110V, 120V, 200V, 220V, 230V, 240V, 250V etc. optional |
IS-2KVA | 2KVA | ||||
IS-3KVA | 3KVA | ||||
IS-4KVA | 4KVA | ||||
IS-5KVA | 5KVA | ||||
IS-6KVA | 6KVA | ||||
IS-8KVA | 8KVA | ||||
IS-10KVA | 10KVA | ||||
IS-15KVA | 15KVA | ||||
IS-20KVA | 20KVA | ||||
IS-30KVA | 30KVA | ||||
IS-40KVA | 40KVA | ||||
IS-50KVA | 50KVA | ||||
IS-60KVA | 60KVA | ||||
IS-80KVA | 80KVA | ||||
IS-100KVA | 100KVA | ||||
and so on--- | |||||
|
|
|
|
|
|
IST-6KVA | 6KVA | 3P/3P, 3P/1P(optiona) | 50/60Hz | 200V, 220V, 230V, 250V, 380V, 400V, 415V, 430V etc. optional | 200V, 220V, 230V, 250V, 380V, 400V, 415V, 430V etc. optional |
IST-8KVA | 8KVA | ||||
IST-10KVA | 10KVA | ||||
IST-15KVA | 15KVA | ||||
IST-20KVA | 20KVA | ||||
IST-30KVA | 30KVA | ||||
IST-40KVA | 40KVA | ||||
IST-50KVA | 50KVA | ||||
IST-60KVA | 60KVA | ||||
IST-80KVA | 80KVA | ||||
IST-100KVA | 100KVA | ||||
IST-150KVA | 150KVA | ||||
IST-200KVA | 200KVA | ||||
IST-250KVA | 250KVA | ||||
IST-300KVA | 300KVA | ||||
IST-400KVA | 400KVA | ||||
IST-500KVA | 500KVA | ||||
IST-600KVA | 600KVA | ||||
and so on--- |
