J-50 cable cutter head electrical wire cable cutter cutting snips 1). For cutting copper and aluminum cables, single strand and double strand
2). Not applicable to shear steel wire and copper hard drawn wire
3). As the torque transmission design is adopted, only a small amount of hand force is required
4). Two-stage ratchet mechanism, easy to cut
5). Compact structure, light weight, easy to operate and even able to operate in a small space
6). Clamp hand protection device
7). Quenching and fine grinding of blade
8). The shear surface is smooth and smooth without burrs and deformation
9). Use special tool steel
10). When cutting, place one of the handles on the supports and press down one of the handles
Product size
Model
Range of shear
Product size
Weight
J-40
Shear single 300mm2 copper and aluminum cable
346x120x38mm
1.1kg
J-52
Single copper aluminum cable with shear diameter up to 50mm
397（stretch568）x165x54mm
2.9kg
J-75
Single copper aluminum cable with shear diameter up to 75mm
416（stretch587）x200x55mm
3.6kg
J-95
Single copper aluminum cable with shear diameter up to 95mm
446（stretch620）x285x55mm
5.7kg
J-100
Single copper aluminum cable with shear diameter up to 100mm
482（stretch655）x270x59mm
6.2kg
J-130
Single copper aluminum cable with shear diameter up to 130mm
524（stretch693）x328x59mm
8.7kg
J-160
Single copper aluminum cable with shear diameter up to 160mm
524（stretch693）x328x59mm
10.9kg
XD-520A
Shear the steel cored aluminum strand within 300mm2
Cut the steel strand within 70mm2
Cut wire rope with diameter less than 12
330（stretch400）x140x55mm
1.9kg
J-13
Shear the steel cored aluminum strand within 700mm2
Cut the steel strand within 120mm2
345（stretch514）x125x46mm
1.95kg
J-30
Shear the steel cored aluminum strand within 630mm2
Cut the steel strand within 100mm2
406（stretch514）x160x64mm
3.4kg
J-25
Shear the steel cored aluminum strand within 800mm2
Cut the steel strand within 150mm2
535（stretch745）x160x60mm
2.8kg
J-50
Shear the steel cored aluminum strand within 1440mm2
400（stretch568）x158x52mm
3.2kg
J-70
Shear the steel cored aluminum strand within 1440mm2
Cut the steel strand within 150mm2
416（stretch587）x200x55mm
3.6kg
Model
Range of shear
Product size
Weight
XLJ-30
Single copper aluminum cable with shear diameter up to 30mm
255x125x38mm
0.96kg
XLJ-40
Shear single 300mm2 copper and aluminum cable
346x120x38mm
1.1kg
XLJ-52
Single copper aluminum cable with shear diameter up to 50mm
397（stretch568）x165x54mm
2.9kg
XLJ-65
Single copper aluminum cable with shear diameter up to 65mm
416（stretch587）x200x55mm
3.6kg
XLJ-75
Single copper aluminum cable with shear diameter up to 75mm
416（stretch587）x200x55mm
3.6kg
XLJ-95
Single copper aluminum cable with shear diameter up to 95mm
446（stretch620）x285x55mm
5.7kg
XLJ-100
Single copper aluminum cable with shear diameter up to 100mm
482（stretch655）x270x59mm
6.2kg
XLJ-120
Single copper aluminum cable with shear diameter up to 120mm
524（stretch693）x328x59mm
8.7kg
XLJ-130
Single copper aluminum cable with shear diameter up to 130mm
