Product Overview

Description













Model

CQDH20C（double  scissor）
Drive type

battery
Capacity / rated load
（kg/lbs)
1600/3527
Lift height
h3(mm/inch)
4500/6000/6500/9000(177.2/236.2/255.9/354.3)
Load centre distance
c(mm/inch)
600/23.6
Height, lowered
h1(mm/inch)
2365/2763/2933/3743(93.1/108.8/115.5/147.4)
Free lift
h2(mm/inch)
1225/1720/1890/2756(48.2/67.7/74.4/108.5)
Height, mast extended
h4(mm/inch)
5604/7104/7604/10104(220.6/279.7/299.4/379.8)
Height of overhead guard (cabin)
h6(mm/inch)
2362/93
Overall length
l1(mm/inch)
3250/128
Length to face of forks
l2(mm/inch)
2180/85.8
Overall width
b1/b2(mm/inch)
1352/1070（53.2/42.1）
Length of fork leg face to rear end
l7(mm/inch)
2286/90
Fork dimensions
s/e/l(mm/inch)
40*100*1070/1.6*3.9*42.1
Reach distance
l4(mm/inch)
1000/39.4
Width overall forks
b5(mm/inch)
200-920/7.9-36.2
Aisle width for pallets 1000x1200 crossways
Ast(mm/inch)
3609/142.1
Aisle width for pallets 800x1200 lengthways
Ast(mm/inch)
3667/144.4
Turning radius
Wa(mm/inch)
2145/84.4
Travel speed, laden / unladen
Km/h
10.5/11
Lift speed, laden / unladen
m/s
0.29/0.29
Service weight (with battery)
(kg/lbs)
5800/12786.8












Q1:Are you a factory?
A1: Of course.Ningbo Ruyi Joint Stock Co. Ltd., established in 1985, is a national hi-tech enterprise, which owns the unique
combination of scientific research,development, production, sale and service. Moreover, the trademark of Xilin has been registered in 68 countries and regions around the world and its products sell well in more than 100 countries and regions until this year.
Q2: Do you have agent or representative abroad?
A2: Yes. We have two branches in the US and Russia. We have two warehouses are located in Los Angles and Chicago with products in stock and ready to ship. We also have Xilin distributors agent in Norway, Thailand, Japan, Vietnam and Malaysia. If you are interesting to be our agent and enjoy more price. Pls contact us then we can discuss more detailed.
Q3: What's the specification of the chargers?
A3: Xilin have all kinds of the chargers and welcome the customers to custom-made.
Q4: Warranty for the product?
Q4：We do offer one year warranty which would cover the failure not caused by miss-usage like over loading or misplacing the item.And There is no warranty for wearing parts such as wheel and fuse.
Q5: How about the delivery time?
A5: Usually Xilin producing time is 15-20 working days after we receive the advanced payment. For some standard products,we have most in stock and could delivery immediately.
Q6:What is your payment term?
A6: T/T or L/C,if you want any other way,please contact us.
Q7: What can I get from cooperating with Xilin?
A7: 1. Unique products, with customized service.2. Timely production and delivery, time is money. 3. Market protection service, long term business strategy.
