HDRM200 IOT 5g 4g Lte CAT4 CAT6 CAT12 CAT 20 Industry wifi Router with 4 high speed LAN Ports and 1 WAN port
- Category: >>>
- Supplier: Shenzhen Ex-link Technology Co. Ltd
Share on (62523472838):
Product Overview
Description
Product Description
HDRM200 IOT 5g 4g Lte CAT4 CAT6 CAT12 CAT 20 Industry wifi Router with 4 high speed LAN Ports and 1 WAN port
Highlight
• 3G/4G LTE /5G data transmission;
• Embedded watchdog , Auto recovery;
• 2*2 4G/WIFI MIMO antenna;
• Integrate 3G/4G LTE,WIFI,GPS feature;
• One WAN,Five LAN(1LAN/1 Gbit LAN & 4 LAN/100Mbps) ports, Support VLAN,LAN Ethernet port.
• One console port, One USB port,RS232 or RS485 Interface,4 line GPIOs;
• SD data storage (Optional);
• With dual SIM card slot;
• Remote management platform;
• Supports wifi 802.11AC, 1.2Gbit
• Supports 50 WiFi users sharing
• Firmware version: Openwrt;
Frequency Bands:
Version C
LTE-FDD. B1,3,7,8 LTE-TDD.B38,39,40,41
WCDMA.900/2100MHz TDSCDMA. band A and band B
GSM.900/1800MHz
Version CE.
LTE-FDD. B1,B3,B8 LTE-TDD.B38,B39,B40,B41
WCDMA.900/2100MHz
CDMA 1X/EVDO BC0 TDSCDMA. B34,B39
GSM.900/1800MHz
Version E.
LTE-FDD. B1,3,7,8,20 LTE-TDD.B38,40
WCDMA.900/2100MHz GSM.900/1800MHz
Version A.
LTE-FDD. B2,4,5,17
WCDMA.850/1900MHz
Version SA.
LTE-FDD. B1/B3/B4/B5/B7/B8/B28
LTE-TDD B38/B40/B41
UMTS/HSDPA/HSPA+ B1/B2/B5/B8
GSM/GPRS/EDGE B2/B3/B5/B8
Version JC
LTE FDD. B1,B3,B8,B18,B19
LTE TDD. B41 UMTS. B1,B6,B8 GSM. 900/1800MHz
Version JE
LTE FDD. B1,B8 UMTS. B1,B8
GSM. 900/1800MHz
Data Rate | ||
3G Router | WCDMA | Download Rate 14.4Mbps, Upload Rate 5.76Mbps |
EVDO | Download Rate 3.1Mbps, Upload Rate 1.8Mbps | |
4G Router | LTE FDD | Download Rate 100Mbps~300Mbps, Upload Rate 50Mbps |
LTE TDD | Download Rate 50Mbps, Upload Rate25Mbps | |
HSPA+ | Download Rate 42Mbps, Upload Rate 5.76Mbps | |
TD-SCDMA | Download Rate 2.8Mbps, Upload Rate2.2Mbps | |
GPRS | Max. 85.6Kbps(Download Rate ), Max. 85.6Kbps(Upload Rate) |
Storage memory | Support SD data storage |
RF | High gain WIFI, 4G LTE, GPS antenna |
Security Encryption | Support WEP,WPA,WPA2 encryption ways |
Protocol | PPTP,L2TP,IPSEC VPN,TCP,UDP, DHCP,HTTP,DDNS,TR-069,GRE, HTTPS, SSH,Open VPN,SNMP |
Advertising push | Support portal protocol, User login interface jump |
Data traffic management | Support Traffic monitoring and bandwidth limitation |
LED Indicator | "SYS", "Net", "WAN", "LAN",RSSI |
SIM/UIM | Standard draw card interface, support 1.8V/3V SIM/UIM card, built-in ESD protection |
Key button | Reset, WPS |
Standard Power | DC input: DC 12V/1A |
Power Supply | DC input: DC 5~48V |
Working current | 2A (Max Current) |
Operating Temperature | Temperature -40~+80ºC |
Storage Temperature | Temperature -45~+85ºC |
Environment humidty | 95% |
Case | Black steel case |
Size | 125mm*105mm*25mm |
Weight | 225g |
Main Features
1). Industrial designing, including wide temperature range, wide voltage Range and ESD, making it stable and reliable;\t
2). Provide 1 WAN/5 LAN/RS232/RS485/USB/GPIOs communication interface.\t
3). Support global frequency bands. Support dual SIM card load balance.Support GPS location.\t
4). Support SD card storage
5). Support Linux or Openwrt\t\t\t
Certifications
CE, Rohs FCC certifications are on going
Detailed Images
Machine Parts
Name: 4g LTE wireless router with GPS
Brand: Headele Weblink
Original: China
Function: Support Openwrt and SDK firware version.
GPS optinal
Main Features
Name: 4g LTE wireless router
Brand: Headele Weblink
Original: China
Supports WiFi 802.11b/g/n, 300MHZ,
WiFi AP and AP client.
Supports TCP/IP, UDP, FTP, HTTP network protocol.
TR-069
CAT3, CAT4, CAT6 can be support.
