SIT65HVD08P IC single transceiver chip stock price replace SN65HVD08P SN65HVD08

Product Overview

Description

SIT65HVD08P IC single transceiver chip stock price replace SN65HVD08P SN65HVD08



Sit65hvd08 is compatible with sn65hvd08. Sit65hvd08 is a RS485 transceiver chip with 3.0V ~ 5.5V wide power supply, bus port contact discharge capacity of more than 16Kv, bus withstand voltage range of 15V, half duplex, low power consumption, and fully meet the requirements of TIA / eia-485 standard.

Sit65hvd08 includes a driver and a receiver, both of which can be enabled and closed independently. When both are disabled, both the driver and the receiver output the high resistance state. Sit65hvd08 has 1 / 8 load, which allows 256 sit65hvd08 transceivers to be connected to the same communication bus. It can realize error free data transmission up to 10Mbps.
