ZPFM721 Series Optical Performance Parameters
Red light wavelength: 665nm;
Blue light wavelength: 445nm;
Electric-optical conversion efficiency: about 38%, 2.1umol / J;
* Spectrum combinations can be designed for customers based on the application.
Electrical performance parameters of ZPFM721 series
Single drive:
Input voltage: 100 ~ 240Vac, 277Vac;
Input current see different power nameplates;
| No. | PN | Model | Power(Watt) | PPF(umol/S) | N.W(kg) |
| 1 | 800009097 | ZPFM721-200 | 200 | 420 | 4.5 |
| 2 | 800009095 | ZPFM721-300 | 300 | 630 | 7.1 |
| 3 | 800009098 | ZPFM721-400 | 400 | 840 | 8.9 |
| 4 | 800009099 | ZPFM721-500 | 500 | 1050 | 11.6 |
| 5 | 800009100 | ZPFM721-600 | 600 | 1260 | 14.2 |
| 6 | 800009101 | ZPFM721-900 | 900 | 1890 | 21.3 |
