Automotive parts ultrasonic cleaner industrial ultrasonic cleaner for injectors
Product Description
KER series ultrasonic cleaner is intelligent integrated type ultrasonic cleaning system to washdifferent components quickly with all-in-one and advanced design. lt is realized the optimal hu-man-computer interaction, integrated the most effective cleaning technology. Its one-touch op-eration minimized manual operation works during the cleaning process.
Model
Effective Tank Size
Overall Dimensions
Effective Tank Capacity
Ultrasonic Power
Transducer
Heating Power
KER-2400
600x480x390mm
1260x980x940mm
112L/29.6 Gal
2.4 KW
100W, 24pcs
4 KW
KER-3000
750×550x390mm
1410x1050x980mm
160L/42.3 Gal
3.0 KW
100W.30pcs
8 KW
KER-4000
1000x550x420mm
1660x1050x1100mm
231 L/61 Gal
4.0 KW
100W, 40pcs
12 KW
KER-6000
1200x650x490mm
1860x1150x1180mm
382 L/100.9 Gal
6.0KW
100W, 60pcs
15 KW
KER-8000
1450x720x570mm
2010x1220×1260mm
595 L/157.2 Gal
8.0 KW
100W,80pcs
18 KW
KER-10800
1500x800x640mm
2060x1300×1330mm
768 L/202.9 Gal
10.8KW
100W, 108pcs
30 KW
KER-12000
1700x900x640mm
2260x1400x1330mm
979 L/ 258.6 Gal
12.0 Kw
100W,120pcs
45 KW orSteam
KER-24000
2500x1200x840mm
3060x1700x1530mm
2520 L /665.7 Gal
24.0 KW
100W,240pcs
90 KW orSteam
>> The ultrasonic generator, cleaning tankand control system are all integrated inone unit, easy to operate
>> Ultrasonic transducers are placed intransducer packs, which are easily re-placed after end of life.
>> Transducers packs are uniformly ar-ranged in multi directions of cleaningtank for more homogenous, thoroughlyand better cleaning efficiency
>> PLC& HMI control system has automaticand manual two working modes. Cleaning parameters can be set easily.Networking function allows remote debug-ging and PLC program update in time
>> Fault & maintaining reminding function;Emergency stop button is installed;
>> Equip with circulation and filtration system.Equip w ith oil skimmer and liquid level pro-tector.
>> Electronic components and parts comefrom world-famous brands
>> Lifting device with up-down-shakingmovement function makes heavy dirtdrop easily. (Optional)
Before & After
Product Application
lt can be used for different sized metal, plastics, ceramics parts for prewashing, inter-opera-tional washing, or final washing, with the possibility of anti-corrosive protection to removes oil,grease, chips, mud, production slag of the surface of parts.
Packaging & Shipping
Related Products
Company Information
KEER is an environmental engineering and automation firm providing industrial parts cleaning solutions for a wide range of industrial activities. We offer our clients comprehensive industrial cleaning solutions, covering the following services: analysis, planning, design, construction, installation, maintenance and supply of related chemical agents for industrial cleaning. Ever since the inception of our company we have promoted the implementation of the best available technologies, so as to ensure our clients are offered the best solutions for their specific needs. We own a subsidiary export firm Keer International in providing our international clients with professional consulting and sales service.
Our Services
FAQ
Q1: IS THERE ANY DIFFERENCE IN ULTRASONIC CLEANERS? Ultrasonic cleaners come in 3 categories, Mini type for cleaning contact lenses, etc. These are very light duty cleaners with small transducers and very simple generators that are not very efficient.They should never be usedfor critical cleaning jobs. The second type are the dental cleaners and small lab size tabletop cleaners, these have aheaver transducer and a better generator and are efficient in cleaning small parts and labglass. The third type is the industrial heavy-duty type with very heavy compound transducersand rugged generators that produce high wattage per transducer. These clean more efficientlyand can be used for production cleaning. Tanks are heavy-duty welded 304 or 316L stainlesssteel with overflows and drain ports. Our KR series are this type.
Q2: HOW TO CHOOSE ULTRASONIC FREQUENCY? Ultrasonic requency is suggested based on cleaning objects'material and pollutants in theobjects. Most ultrasonic cleaners operate between 20 and 120 KHz. The system frequency touse depends on the type of cleaning required. The lower frequencies produce larger cavitation bubbles with more abrasive cleaning.Thesefrequencies are recommended for coarse cleaning needs such as removal of lapping compounds from durable metal surfaces. For fine cleaning of very delicate items such asjewelry and soft metals with polished surfaces, higher frequency may be more suitable.
Q3: HOW TO CHOOSE A GOOD ULTRASONIC CLEANER? Frequency: Choose the suitable ultrasonic frequency according to the above suggestions.Inner size of cleaning tank: It should be bigger than cleaning objects' size. Core element: The core element of an ultrasonic cleaner is ultrasonic transducer. The qualityof ultrasonic transducer influences the service life of an ultrasonic cleaner greatly. Ultrasonic power: The larger the volume of solution, the more ultrasonic power will be neededfor cleaning. Most cleaners run at an average power of 50 to 100 watts per gallon, so thelarger the tank the more power you need. Simply to say, we can think more power usuallyindicates faster and more effective cleaning.
