Kapton Polyimide Heater PI Heating Film Plate Electric Heated Panel Pad Mat Electrotherma Flexible Adhesive Foil
- Category: >>>
- Supplier: Yancheng Dezheng Technology Limited
Share on (62532386753):
Product Overview
Description
Product Description
Polyimide is a thin, lightweight organic polymer film which provides excellent tensile strength, tear resistance and dimensional stability. This heater is ideal for applications requiring low outgassing in a vacuum, or resistance to radiation, fungus and chemicals. Polyimide is also solvent resistant.
Specification
Voltages available | 380V,240V, 220V,110V,36V,24V or 12V |
Length range | 10mm-6000mm |
width range | 10mm~500mm |
Thickness range | Standard:0.126~0.266mm(0.005"~0.01") |
Internal thermocouple | type J or K |
Power | 1-6.5w/cm2 |
Size | based on your requirements |
Power density range | 0.03w/cm2~2.5w/cm2(0.19w/inch2~16.13w/inch2) |
Application
1.Medical equipment such as blood analyzers and test tube heaters
2.Computer peripherals such as laser printers
3.Curing of plastic laminates
4.Photo processing equipment
5.Semiconductor processing equipment
6.Thermal transfer equipment
7.Heat various vessels and objects including...
2.Computer peripherals such as laser printers
3.Curing of plastic laminates
4.Photo processing equipment
5.Semiconductor processing equipment
6.Thermal transfer equipment
7.Heat various vessels and objects including...
Products Show
Features
1.Withstand temperature extremes from -56°C to 200°C (-70°F to 392°F)
2.Excellent tensile strength, and tear resistance
3.Low out-gassing
4.Small, flexible radius
5.Chemical resistance to many solvents and oils
2.Excellent tensile strength, and tear resistance
3.Low out-gassing
4.Small, flexible radius
5.Chemical resistance to many solvents and oils
