Optical Mark Reader(OMR) is a high-tech data input device which is integrated with optical and electrical technique. OMR solves entirely the bottleneck problem of data input. It is a powerful tool for speedy automatic data capture. The speed is several hundreds of times faster than that of manpower; especially the machine can work for a long time without break. So nothing else can instead OMR so far. It can be used in all kinds of standard examination and students’ information statistics
Specification of OMR
Model: OMR960D Reading mode: Single-face and read one time
Feeding mode: Automatic
Speed: 8000PCS/hour (based on A4)
Form size: 130mm× 50mm-300mm× 210mm
Form weight: 70-150G/M2
Track spacing: 5.08/4.23mm
Marking tools: No. 2 or softer pencils, carbon pens
Mark shapes: Rectangles, ovals and circles
Error rate: ≤ 1× 10-7
Mark choice: Single choice, multiple choice and BCD code
Format: 26 kinds, each has 255 commands at most
Interface: RS232, USB
Host: PC, Laptop
Weight: 8kg
Operating system: Win2000, Win2003, Win XP
Power supply: AC100-240V, 50-60Hz
Dimensions: 560mm× 170mm× 400mm
Operating condition: Temperature 0-40° C, humidity≤ 90%, no erosive gas
Packaging & Shipping
The package : Carton
The Net Weight : 8KG
The delivery time : 2-3 work days by DHL
Our Services
Thanks for purchase our products , Our company promises seriously to our sustomers; we can provide the service of maintaining for free within 2 years ,service else always
The Service of maintaining whithin2 years
In case that machine has some malfunction brought by quality of manufacture, you can tak it to maintenance organization authorized by us to maintain it for free
