10th Generation Intel Core i7 10510U Industrial PC, Fanless PC With Rich IO: HD MI DP Dual DDR4 USB3.0 Aluminum Case 4K Display
- Category: >>>
- Supplier: Dongguan Tuofuton Electronic Technology Co. Ltd.
Share on (62532842637):
Product Overview
Description
Product Description
Key Features | CPU | 1. 10th Gen 14nm CPU Intel Core i7 10710U 6 cores 12 threads 1.1GHz up to 4.7GHz 12MB cache TDP 15W Intel UHD Graphics. 2. 10th Gen 14nm CPU Intel Core i7 10510U 4 cores 8 threads 1.8GHz up to 4.9GHz 8MB cache TDP 15W Intel UHD Graphics. 3. 8th Gen 14nm CPU Intel Core i7 8565U 4 cores 8 threads 1.8GHz up to 4.6GHz 8MB cache TDP 15W Intel UHD Graphics 620. |
RAM | Support 2*DDR4-2133/2400/2666 non-ecc laptop ram Maximum 64GB | |
Storage | Support 1*mSATA SSD+1*M.2(NVMe) SSD+1*2.5'' SATA HDD/SSD installation together | |
Graphics | Intel UHD Graphics, support ultra HD 4K resolution | |
I/O | Mic; Speaker; 4* USB 3.0 port; 4* USB 2.0 port; 1* RJ45 Gigabit LAN Port; 1* VGA(DP); 1* HDMI; 1* DC In; | |
Operating System | Windows10, Linux Compatible, OpenELEC | |
Language | Multi Language | |
Feature | Fanless system design, without noise | |
USB port | 4*USB 3.0+4*USB 2.0 | |
Wireless | 802.11.b/g/n, 300M 2.4G/5G dual band WiFi with 2 Antennas | |
HD Output | 1* HDMI port, 1*DP port, support HDMI+DP dual display | |
LAN port | 1* Gigabit Realtek RJ45 Lan speed up to 1Gbps | |
Power and Environment | Input | DC100-240V AC/50-60Hz |
Output | DC 12V-19V~3A/5A | |
Operating Temperature | 0/70 Centigrade (32F~140F) | |
Storage Temperature | -20/+85 Centigrade | |
Relative Humidity | 0%~90% (non-condensing) | |
Energy-saving | Support Energy-saving technology, Speedstep | |
64 bit computing | Support 64 bit computing | |
Virtualization | Support Virtualization technology | |
Hyper-threading | Support Hyper-Threading | |
Consumption | 15W~28W | |
Physical Properties | Material | Brushed Aluminum Alloy |
Weight | NW:2.0Kg GW:2.5Kg | |
Package Content | 1* Mini PC; 1* power adapter; 2* Antennas etc | |
Warranty | 30 days free defective replacement and 3 years free repair |
- Processors parameter for referance only:
1. Upgrade DDR4 ram to 2400MHz free!
2. Upgrade 2.4G/5G dual band WiFi free!
3. Upgrade Msata SSD to fast M.2 NVME/PCIE3.0x4 SSD free!
1. 10th Gen 14nm CPU Intel Core i7 10710U 6 cores 12 threads 1.1GHz up to 4.7GHz 12MB cache TDP 15W Intel UHD Graphics.
2. 10th Gen 14nm CPU Intel Core i7 10510U 4 cores 8 threads 1.8GHz up to 4.9GHz 8MB cache TDP 15W Intel UHD Graphics.
Hi'g'h'light
1)-Advanced newest intel processor, assure powerful performance for gaming, office, drawing;
2)- 2*DDR4 RAM slots 2xfaster than 1 ram slot, DDR4 2xfaster than DDR3;
3)- Noiseless: Fanless system, all aluminum passive heatsink, low consumption, 0.00dB noise;
4)- Triple-Storage: support 1*Msata SSD+1*M.2 NVME(22x80) SSD+1*2.5'' SATA SSD/HDD;
5)- Slim volume: Can stand on desk by free bracket we supply, mount back of monitor by VESA bracket(optional);
2)- 2*DDR4 RAM slots 2xfaster than 1 ram slot, DDR4 2xfaster than DDR3;
3)- Noiseless: Fanless system, all aluminum passive heatsink, low consumption, 0.00dB noise;
4)- Triple-Storage: support 1*Msata SSD+1*M.2 NVME(22x80) SSD+1*2.5'' SATA SSD/HDD;
5)- Slim volume: Can stand on desk by free bracket we supply, mount back of monitor by VESA bracket(optional);
Package Content
1* Mini PC;
1* power adapter;
2* Antennas etc
1*power cable
1*VESA bracket (optional)
1*SATA cabel
1*CD
Related Products
Company Profile
Topton Technology Co., Limited established in 2016, is a manufacturer, trader and wholesaler in line with the latest computer technology, good quality, reasonable prices and nice service. Before Topton comes online, our factory in Shajin, Shenzhen already producing and supplying thin client and mini computer hosts since 2006. Now we devotes into fanless system mini pc supplying. With our deeply-accumulated experience and knowledge of oversea marketing, Topton soon gets worldwide markets, including Latin America,Asia, Africa and some European countries. Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
Why Choose Us
Advantage
1.Product quality : Quality is the best important for co-opertion .Our technical install RAM,SSD,WIFI and operation system to test
each PC although barebone system your bought .Then every PCs must get through high quality test for a least 2 hours .
2.Brand configuration : Every pieces of accessories (memory, storage ,wireless card etc) , we used famous brands or chinese brand with top quality .
3.Service : Pricing , Selling , After-sale etc.
4.OEM : We accept OEM Service (such as logo printing , box , packing )
5.Leading time : We working with DHL Express to ensure the package will be transportated within 10 days .
6.Brand profection :We are a brand company and we will not Cheating customers 。
each PC although barebone system your bought .Then every PCs must get through high quality test for a least 2 hours .
2.Brand configuration : Every pieces of accessories (memory, storage ,wireless card etc) , we used famous brands or chinese brand with top quality .
3.Service : Pricing , Selling , After-sale etc.
4.OEM : We accept OEM Service (such as logo printing , box , packing )
5.Leading time : We working with DHL Express to ensure the package will be transportated within 10 days .
6.Brand profection :We are a brand company and we will not Cheating customers 。
FAQ
Q1. Can you provide OEM/ODM service? How much do I need to pay for your OEM service?
Re: Yes we can. The charges for OEM service depends on the different level of customize. the process of customization is
following:
1) provide your specific requirement.
2) our design engineer draw the design draft.
3) you confirm the design draft.
4) we start produce it.
Q2. Can you print my logo on the mini computer ?
Re: Yes, it is support . And we could print your logo on the pc for free !
Pls contact me for logo printing ;)
Q3. What is the Minimum Order Quantity (MOQ)?
Re: We can sell one piece sample for your test.
Q4. What is the lead time of your products?
Re: Sample order within 3-7 business days . Bulk order within 3~15 business days ( depends on order qty) ,we will test the model
to insure the quality before shipping.
Q5. How will you deliver my goods to me?
Re: We ship by air generally. In the meantime, we cooperate with international expresses such as DHL, UPS, FedEx, and TNT to
enable our customers to get their goods rapidly.
Q6.What's the warranty?
Re: 3 year warranty ! After expired warranty and sent back to our company, we will still try our best to repair for you without
repair cost (except change new accessories)
Re: Yes we can. The charges for OEM service depends on the different level of customize. the process of customization is
following:
1) provide your specific requirement.
2) our design engineer draw the design draft.
3) you confirm the design draft.
4) we start produce it.
Q2. Can you print my logo on the mini computer ?
Re: Yes, it is support . And we could print your logo on the pc for free !
Pls contact me for logo printing ;)
Q3. What is the Minimum Order Quantity (MOQ)?
Re: We can sell one piece sample for your test.
Q4. What is the lead time of your products?
Re: Sample order within 3-7 business days . Bulk order within 3~15 business days ( depends on order qty) ,we will test the model
to insure the quality before shipping.
Q5. How will you deliver my goods to me?
Re: We ship by air generally. In the meantime, we cooperate with international expresses such as DHL, UPS, FedEx, and TNT to
enable our customers to get their goods rapidly.
Q6.What's the warranty?
Re: 3 year warranty ! After expired warranty and sent back to our company, we will still try our best to repair for you without
repair cost (except change new accessories)
