Product Overview
Description
vertical band saw
The vertical band saw mainly use for round and square woodcutting, it can work with worktable or log carriage. Our band saw body is cast-iron, saw wheel made by steel, after processing by CNC Lathe, dynamic balance test and our quality control it can working long life. We can provide electric, petrol and diesel engine power. All our band saw can customer made as your requirement.
Band saw machine parameter
Model | YMJ329 | YMJ3210 | YMJ3210A | ||
Maximum log cutting Dia | 650mm | 800mm | 800mm | ||
Saw wheel diameter | 900mm（36inch） | 1000mm（40inch） | 1060mm（42inch） | ||
Saw wheel rpm | 750r/min | ||||
Saw guide elevate | Manual / Automatic（Optional） | ||||
Saw wheel elevate | Manual / Automatic（Optional） | ||||
Saw blade spec | 1.05*125*6400mm | 1.15*125*6900mm | 1.15*125*7100mm | ||
Motor power | 18.5kw（25HP） | 22Kw（30HP） | 22Kw/30Kw（Optional） | ||
Voltage | 380V/50Hz/3Phase（Customized） | ||||
Weight | 1000kg | 1100kg | 1350kg | ||
Overall size(L*W*H) | 1160*900*2040mm | 1260*1000*2300mm | 1360*1060*2400mm | ||
How to choose the band saw / Log carriage ?
1. Minimum - maximum diameter of your wood
2. Minimum - maximum length of your wood
3.Power:
(1) Standard voltage 380V/50Hz/3Phase, can be customized according to customer requirement
(2) Diesel / petrol engine is optional
4. Hardness and kinds of your log
5. Production requirements (daily or monthly)
About YSDMILL.
Xingtai Yashida Machinery Manufacturing Co., Ltd. has professional design and R&D team. It produces various types of wood band saw machine and CNC automatic log carriage with functions such as hydraulic, pneumatic headblock and clutch system, hydraulic automatic turning wood and hydraulic pneumatic pendulum. Maximize labor savings and increase work efficiency. It is the preferred solution for the replacement of band saws on the market.
