LC/APC Simplex Fiber Optic Fast Connector price
- Category: >>>
- Supplier: Shenzhen Runxiang Telecommunication Technology Co. Ltd.
Share on (62535905303):
Product Overview
Description
LC/APC Simplex Fiber Optic Fast Connector price
ITEM | Technical Parameters |
Applicable for | Drop cable.Indoor cable |
Optical fiber diameter | 125μm ( 657A & 657B ) |
Tight buffer diameter | 250μm |
Fiber mode | Single mode |
Operation time | About 100s(no fiber cut) |
Insert loss | ≤ 0.3dB(1310nm & 1550nm) |
Return loss | ≤ -40dB |
Fastening strength of naked fiber | >5 N |
Fastening strength of naked fiber holder | >10 N |
Tensile strength | >50 N |
Using temperature | -40~+75°C |
On-line tensile strength (20 N) | Δ IL ≤ 0.5dB Δ RL ≤ 5dB |
Mechanical durability (500 times) | Δ IL ≤ 0.5dB Δ RL ≤ 5dB |
Drop-off test (drop-off height 4m, once per direction, totally 3 times) | Δ IL ≤ 0.5dB Δ RL ≤ 5dB |
Charateristics
1.High-precision Mechanical
2.High Environmental Stability
3.Light and Handy Body45.Long WEorking Life
4.Mulit-gear SnapJjoint, More Stable
5.High quality ceramic ferrule,low insertion loss,High return loss
6.High repetition- use
7.Easy installation and maintenance
2.High Environmental Stability
3.Light and Handy Body45.Long WEorking Life
4.Mulit-gear SnapJjoint, More Stable
5.High quality ceramic ferrule,low insertion loss,High return loss
6.High repetition- use
7.Easy installation and maintenance
Application
—Patch panels
—Distribution frames
—Maintenance or emergency restoration of fiber networks
—FTTH Outlets
—Connection at the desk for LAN environments
—Suitable for FTTx butterfly type cable(both square and circle shape are available)
—Distribution frames
—Maintenance or emergency restoration of fiber networks
—FTTH Outlets
—Connection at the desk for LAN environments
—Suitable for FTTx butterfly type cable(both square and circle shape are available)
