UL Rohs Charge 12s 43.8v 24v 29.2v 1a 1.45a 1.9a 2a 2.5a 3a 3.5a 4a 4.5a 5a 6a 7a 8a 9a 10a 11a 12a 20a Lifepo4 Battery Charger
- Category: Game Player Chargers >>>
- Supplier: Fuyuan Electronic Co. Ltd
Share on (62536253335):
Product Overview
Description
UL Rohs Charge 12s 43.8v 24v 29.2v 1a 1.45a 1.9a 2a 2.5a 3a 3.5a 4a 4.5a 5a 6a 7a 8a 9a 10a 11a 12a 20a Lifepo4 Battery Charger
24v 20a Rohs 9a 8a 7a 6a 5a 4a 3a 3.5a 29.2v 12s 12a 11a 10a 1.9a 1a 1.45a Charge Battery 4.5a Lifepo4 Charger 2a 43.8v 2.5a
| Product name | Universal 12V 24V 36V 48V 63V 72V LIFEPO4 battery charger |
| Certificate | CCC, UL, cUL, CE, GS, PSE, SAA,C-Tick RCM, KC, KCC, CB TUV ROHS, BS |
| Usage | Robot, Electric vehicle, Ebike, Electric Scooter, Mortor, Golf car,Solar Systems, Home Application, UPS,LED Torch, headlight, Portable power bank, etc. |
| Package | PE bag+ White box+ Carton |
| Environmental Protection | RoHS, REACH, CPSIA or PAHs Compliant On Request |
| Protection Function | Over voltage protection
Over current protection Over-load protection Short circuit protection |
| Energy Standard |
MEPS CEC-V ERP V Energy Star: Level 6 Standby Power: <0.3W |
| Electrical Specification |
Input Plug: EU US UK AU South Korea South Africa Power cords Output Voltage Range of main products: 3.65~84V DC (Optional) Output Current Range of main products: 0.5-40A (Optional) Charge mode: CC--CV (lifepo4 battery charger) |
| Operation And Storage Condition | Operation Temperature: -20°C to 40°C
Operation Humidity: 20% to 90% R.H Storage Temperature: -20°C to 75°C Storage Humidity: 1% to 90% R.H. MBFT: > 50,000Hours |
♦ AQL :MIL-STD-105E II CRI 0; MAJ 0.25; NIN 1.0
♦ MTBF:30000 hours full rated load at 25oC
♦ Drop Testing:Meet UL standard
♦ Working Mode:Constant Voltage
♦ Package:PE bag+ White box+ Carton
6V Float Voltage: 6.8V(6.7-6.9V), Top Voltage: 7.3V(7.2-7.4V)
12V Float Voltage: 13.8V(13.6-14.0V), Top Voltage: 14.6V(14.4-14.8V)
18V Float Voltage: 20.7V(20.4-21.0), Top Voltage: 21.9V(21.6-22.2V)
24V Float Voltage: 27.6V(27.2-28.0), Top Voltage: 29.2V(28.8-29.6V)
36V Float Voltage: 41.4V(41.3-42.0), Top Voltage: 43.8V(43.5-44.4V)
48V Float Voltage: 55.2V(54.8-55.6), Top Voltage: 58.4V(58.0-59.2V)
60V Float Voltage: 69.0V(68.5-69.5), Top Voltage: 73.0V(72.5-74.0V)
♦ Led display: Red--in charging; Green--fully Charge
♦ Cut-off Current: 10-15% of Charge current
♦ Output Connector: 3pin Aviation Plugs, XLR socket, DC Jack, Alligator Clips, SAE connector, Anderson Plugs, RCA
♦ Ripple & Noise:1% of Output Voltage
