JRT60 Portable Line Boring Machine is a proven dependable and extremely powerful on-site boringmachine. A versatile and modular line boring machine offering a choice of electric and hydraulic boring bar drive motors, with a mechanical drive for the feed assembly.
Whether it's conventional boring,drilling,facing or grooving,the JRT60 has you covered. With versatile setup & machining options,it's the machine you need to get all your toughest jobs done when and where you need it
•Modular components make setup quick and easy
•Through-bar design allows the rotational drive and feed unit to be mounted anywhere along the bar.
•Mechanical bi-directional variable auto-feed
•Drive and feed units which accept a variety of boring bar diameters
•Modular add-on components provide a flexible line boring solution for multiple projects: Blind boring, Line boring, Facing, Drilling, Grooving.
•Available in electric,servo or hydraulic motor configurations.
Specification
Boring Bar Diameter
60mm
Standard Length of The Boring Bar
2000mm (Customizable)
Boring Diameter Range
63.5-609.6mm
Power unit
Eibenstock motor/servo motor/hydraulic
Roating Speed
100rpm --infinite variable speed
Boring Stroke
305mm/610mm/915mm(Customizable)
Standard Accessories and Components
Boring Bar (60*2000mm)
1Pc
Rotational drive unit (RDU)
1Pc
Servo motor 2.5Kw
1Pc
Electric 220V control box (servo motor)
1Pc
Axial feed unit (AFU)
1Pc
Leadscrew 610mm (24'')
1Pc
Single arm mount
2 Pcs
60mm bar small setup cone 70 - 212.6mm (2.75'' - 8.37'')
2 Pcs
60mm bar medium setup cone 212.6 - 304.8mm (8.37'' - 12'')
2 pcs
60mm bar large setup cone 304.8 - 609.6mm (12'' - 24'')
2 Pcs
Tool heads, 63.5 - 304.8mm (2.5'' - 12''), 3 pcs
1 Set
Tool heads, 304.8 - 609.6mm (12'' - 24''), 3 pcs
1 Set
Tool kit (16mm Hss tool bit - 50mm)
2 Pcs
Installation tools
1 Set
Manual
1 Pc
If you need customized configure or configure your own JRT60, please kindly contact us.
Packing & Delivery
JRT60 portable line boring machine is packed into 2 iron case, suitable for ocean delivery.
Company Profie
Xinxiang JieRui Machine Tool Co., Ltd is an innovated company, aims to be the leader in the portable machine tools. Though we are young in this industry, we will always insist on scientific and technological innovation and do our best to catch up with global advances. One day, we will be the main strength that raises the field standardization to a new level.
JieRui will never be satisfied with the achievement that has been made. We continuously enlarge our products line and
production capacity. Now our products cover portable line boring machine, portable flange facer, portable milling machine, circular mills, portable lathe, portable valve repair machine, etc. More importantly, over a decade of development, we own key patents of our products.
We know customers' needs and cares about customers' benefits. Offering customers stable and high-efficient portable
machine tools is our first mission. We will always be your trustful partner. We will never compete with our customers.
FAQ
1.Are you manufacturer or trade company? We are Professional manufacturer of portable machine tools.
2.Can you help us choose the right machine? Yes, We can. Specify your needs. Like : the diameter of bore, the distance between the two holes. If you can offer us the workpiece drawing or photos will be better. We will recommmed you the proper machine or do custom design for you.
3.What kind of portable machine tools do you manufature? Now our products cover portable line boring machine, portable flange facer, portable milling machine, orbital milling machine, portable lathe, portable valve repair machine, etc.
4.How to pay it? We accept many type of payment. T/T, L/C, Paypal, West Unit, Trade Assurance, and other type of payment.If you haven't used these payment before, we can teach you to use them with you.
