14inches YWF 4E 400 Ventilation and heat dissipation of plant exhaust fan 220v ball bearing copper wire carport ventilation
- Category: >>>
- Supplier: Linyi Tongxin Electric Co. Ltd.
Share on (62537342523):
Product Overview
Description
Product advantage
(Low Price Industrial Fans with CE Certificate)
1.Profuse designs with series quality grade fan&motor manufactruer
2.Competitive price,high quality---CE& ISO9001
3.Low noise,large air volum
The biggest advantage of our products is:"Low noise, Big Air flow High stabiltiy, high efficiency".
Low noise: we adopt two-sides banlances on fan, Vibration speed virtual value of fans ≤0.5 mm/s
High stabitility: we test every fan and blowers before shipment, and life time more than 30000 h
High efficiency: our fan adopted the specical design to keep the best banlance betwwen Air flow and Noise.
Quality policy: Carefully planned,Well designed,Painstakingly created,Meticulous service.
| MODEL | VOLTAGE (V) | FREQUENCY (Hz) | SPEED (R/min) | INPUT POWER (W) | NOISE (dB/A) | AIR VOULME (M3/H) | OPERATING TEMPERATURE (Min/Max℃) |
| TX2E-200 | 220 | 50/60 | 2650 | 65 | 63/66 | 1050 | -30/+60 |
| TX2D-200 | 380 | 50/60 | 2650 | 65 | 63/66 | 1080 | -30/+60 |
| TX2E-250 | 220 | 50/60 | 2550 | 80 | 68/73 | 2650 | -30/+60 |
| TX2D-250 | 380 | 50/60 | 2550 | 80 | 68/73 | 2600 | -30/+60 |
| TX2E-300 | 220 | 50/60 | 2850 | 100 | 68/73 | 3250 | -30/+60 |
| TX2D-300 | 380 | 50/60 | 2750 | 100 | 68/73 | 3300 | -30/+60 |
| TX2E-350 | 220 | 50/60 | 2650 | 120 | 68/73 | 5850 | -30/+60 |
| TX2D-350 | 380 | 50/60 | 2650 | 120 | 68/73 | 5930 | -30/+60 |
| TX4E-400 | 220 | 50/60 | 1380 | 180 | 68/70 | 5800 | -30/+60 |
| TX4D-400 | 380 | 50/60 | 1380 | 180 | 68/70 | 4800 | -30/+60 |
| TX4E-450 | 220 | 50/60 | 1380 | 250 | 62/68 | 5750 | -30/+60 |
| TX4D-450 | 380 | 50/60 | 1380 | 250 | 62/68 | 5800 | -30/+60 |
| TX4E-500 | 220 | 50/60 | 1380 | 450 | 70/74 | 9150 | -30/+60 |
| TX4D-500 | 380 | 50/60 | 1380 | 450 | 70/74 | 9150 | -30/+60 |
| TX4E-550 | 220 | 50/60 | 1350 | 500 | 70/74 | 11000 | -30/+60 |
| TX4D-550 | 380 | 50/60 | 1350 | 500 | 70/74 | 11000 | -30/+60 |
| TX4E-630 | 220 | 50/60 | 1350 | 600 | 75/79 | 14000 | -30/+60 |
| TX4D-630 | 380 | 50/60 | 1350 | 600 | 75/79 | 14000 | -30/+60 |
Factory
certificate
Packaging & Shipping
Our Services
24 hours online service platform
Considerate&Meticulous Service
1.Warranty:one year warranty foe all products.
2.Privated Labelling:All of axial fan are able to be private labeled.
3.Delivery time:Normal lead time is 10-25 days.
4.Products quality:100% products inspection before delivery.
5.Customized products and cooling products is provide as customer's request.
6.We'll reply you in 12 hours after you send inquiry to us.
Help us to provide preferably product fan for you:
*Fan type:DC/AC/BLOWER/EXTERNAL ROTOR FAN
*Case size(Dimenssions)
*Bearing:Ball/Sleeve
*Rated voltage:5v/12v/24/48/110v/220v/380v
*Speed
*Air flow
*Air pressure
*Noise
*Wire:2/3/4 wires terminal
*Wire length
*Target price
FAQ
1.How about the lifetime about fan?
Life Expectancy:
Dual Ball Bearing:50000 hours
Sleeve Bearing:30000 hours
2.What effects the quoted price for the fan?
The specification(size),bearing type and voltage.
3.Deliveery time?
Sample lea time:3-5 days
Delivery lead time:2 weeks
4.Payment of terms?
Payment by T/T.
100% payment for sample orders.
30% depositand 70% balance before shipment.
5. Delivery ways?
FedEx,DHL,UPS,TNT Door to Door service,By Air,By Sea, etc.
