  • Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM
Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM

Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3 m OEM

Share on (62539701800):


Price:

Quantity:


Product Overview

Description







Xilin 1000kgs 1ton 2200lbs Electric Walkie Straddle Stacker With Adjustable forks Max.lift height 3m OEM








Model

CTDR10-III
CTDR12-III
CTDR15-III
Capacity
Q（kg）
1000
1200
1500
Load centre distance
c（mm）
500
500
600
Load distance, centre of drive axle to fork
x（mm）
795
795
795
Fork height, lowered
h13（mm）
70
70
70
Height, mast lowered
h1（mm）
2145/1895/2145/2295
Max. lift height
h3（mm）
1600/2500/3000/3300
Height, mast extended
h4（mm）
2145/3145/3645/3995
Overall length
l1(mm
2015
2015
2095
Length to face of forks
l2(mm)
890
890
970
Overall width
b1(mm)
1182-1582
1182-1582
1182-1582
Fork dimensions
s/e/l(mm)
35/100/1070(1150)
35/100/1070(1150)
35/100/1070(1150)
Width overall forks
b5(mm)
200-800
200-800
200-800
Aisle width for pallets 800x1200lengthways
Ast(mm
2420
2420
2500
Turning radius
Wa(mm)
1575
1575
1655
Travel speed, laden/unladen
Km/h
5.3/5.6
5.3/5.6
5.8/6(AC)
Lifting speed, laden/unladen
m/s
0.11/0.17
0.1/0.16
0.09/0.16
Battery Voltage, normal capacity K5
V/Ah
24/120
24/120
24/200
Truck weight
kg
760/780/800/825
780/800/820/845
940/960/980/1005








Q1: Are you a factory?
A1: Of course. Ningbo Ruyi Joint Stock Co. Ltd., established in 1985, is a national hi-tech enterprise, which owns the unique combination of scientific research, development, production, sale and service.
Q2: Can Ruyi provide customized products? OEM products or ODM products?
A2: Yes, Ruyi can provide customized products according to your requirement. Both OEM and ODM are acceptable. We do a lot ofnon-standard products, welcome your special custom-made.
Q3: What's the specification of the chargers?
A3: Ruyi have all kinds of the chargers and welcome the customers to custom-made.
Q4: How about the delivery time?
A4: Usually Ruyi producing time is 15-20 working days after we receive the advanced payment. For some standard products, we have most in stock and could delivery immediately.
Q5: Do you have agent or representative abroad?
A5: Yes. We have two branches in the US and Russia. We have two warehouses are located in Los Angeles and Chicago with products in stock and ready to ship. We also have Xilin distributors agent in Norway, Thailand, Japan, Vietnam and Malaysia. If you are interesting to be our agent and enjoy more price. Pls contact us then we can discuss more detailed.
Q6: Can we print the LOGO on products?
A6: Yes, the OEM is available with the permission of our customers.
Q7: What is your payment term?
A7: T/T or L/C, if you want any other way, please contact us.
Q8: What can I get from cooperating with Ruyi?
A8: 1. Unique products, with customized service.
2. Timely production and delivery, time is money.
3. Market protection service, long term business strategy.
