We are the first to introduce fuel saving materials, such as fiber glass chamber, underground exhaust system, which is much better than up-going flue, was the first one who developed mobile crematorium machine, which is now being used by UN(United Nation). For nearly 30 years, we have grown to become the recognized leader of the cremation industry. We set the standard which others attempt to follow.
As a leader with a long history in the manufacturing of human cremation equipment and animal cremation equipment, our commitment to research and development is unsurpassed. Since our inception, we have striven to perfect the packaged cremation retort. We are an international-based crematory company; We select spare parts of our crematories worldwide, only for quality reason.
Product Description
Our cremator serials were developed to meet all existing requirements with high fuel efficiency, equiped with a reliable and elegant way of emission control, which eliminate completely dust or chemical release without the need for prior preparation or subsequent treatment.
At least three minutes retention time, underground exhaust way, all those factors are reasons of ensuring environmental frendly. Long service life of the refractory lining, designed continously cremation make this machine process up to ten bodies within eight ours working time.
our cremator:
1.High capacity - automatically controlled airsupply and damper
2.Recuperation - no additional supply of heat
3.Smokeless, odourless and dust free mission of waste gases complies with environmental requirements
4.Convenient - only a flat hearth to rake
5.Duplicate systems - insurance against power failure
Overall dimensions (mm)
12000L2360W2500H
One-way creeper truck dimensions(mm)
3800L830W800H
Temp of Primary combustion chamber(cent degree)
700~900
Hearth Burning Pressure(Pa)
-5~-10
Injection Blower(kw)
7.5
Air Blower(kw)
7.5
Total Power(kw)
18
Total weight of cremator(ton)
19
Total weight of carrier(ton)
1.2
Ground space(m2)
8.26
Average fuel consumption(kg/case)
3~6
Average time(min/case)
20~35
Exhaust of harmful substances
In conformity with ISO14001
Fuel
Ld light diesel 0~10,Natural Gas, Propane,LPG
Our Services
we will send our technicians to customer site for installation, training and trial run.
Packaging & Shipping
One unit of cremation machine load 1*40HQ container, around 27 Ton Totally
