Factory Supplying Vacuum Cabinet Membrane Press Veneer Machine
- Category: >>>
- Supplier: Shandong,Yuantong,Century,Intelligent,Technology,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Application：
It is used to cover PVC, wood, wood veneer, decorative paper and similar materials on the surface of all types of door, cabinet and furniture.Kit
Features:
1.Wide application,material is heat transfer film,PVC film and etc.It is professional in making PVC wood door,cabinet,other wood furniture.
2.Intelligent temperature controller,heating area adopt energy-gathered reflecting cover,save electricity.
3.Heating tubes are special customized from our factory,can run 24 hours continuously,service life 8000-10000mm,make sure heating material balanced,can’t partial rupture.
4.Heating box is controlled by cylinder,tight closed,beautiful appearance.easy to open and close.
5.Compact structure,easy to operation,takes up small area,no special requirement for factory and infrastructure.can begin production after short training for staff.
Model | BFM-2611 | BFM-2613 | BFM-2600-200 |
Working area（mm） | 2600*1100 | 2600*1300 | 2600*1100 |
Max. forming height（mm） | 50 | 50 | 200 |
Working negative pressure | -0.1MPa | -0.1MPa | -0.1MPa |
Vacuum pump output | 54m³/h (15L) | 54m³/h(15L) | 54m³/h (15L) |
Total power | 20.5 | 20.5 | 20.5 |
Working voltage | 380V/50HZ/3P | 380V/50HZ/3P | 380V/50HZ/3P |
Net Weight(kgs) | 850 | 920 | 950 |
Overall size(mm)（L*W*H） | 2850*1510*1430 | 2850*1710*1430 | 2850*1510*1680 |
Product Advantage
Whole machine net weight meet 900KGS, Other supplier same machine about 600KGS .
The overall stability of the equipment is enhanced after the weight of the equipment increases.
Adopt special thickened 40mm insulation layer , Other supplier use 20mm-30mm
During heating the thickening of insulation layer improves the insulation effect and saves resources.
During heating the thickening of insulation layer improves the insulation effect and saves resources.
3.More safety opening device
Use SC80*300 double cylinder,which can meet 500KG opening force, the connecting lever thickness meet 20mm .more safety . For other supplier connecting lever only about 10mm .
Our machine is automatic film laminating machine ,when the vacuum storage tank pressure is insufficient,the vacuum pump will working automatically ,this way also extend the service life of vacuum pump . But for other supplier usually is manual and without vacuum storage tank.
5.PVC film thickness
Until now we tested the max. membrane press film thickness meet 0.5mm
6.Easy movement
Install four wheels on the machine bottom, easy movement .
7.Two inspection window
This way it is more easy to check the inside working condition .but for other supplier only have one inspection window
8.Install the retainer frame ,more convenient for use .
Customer Feedback
England
England customer use our pvc vacuum press machine for wall decoration making
Mexico
Mexico customer use our PVC Membrane press machine finish door and cabinet board making
Customized products
Function customized
Max forming height meet 200mm/8inch
Color Customized
Painting the color according customer need
Certifications
SGS
SGS certification for my factory
CE
Export to Europe CE certification
Trademark registration
BaoYuanTong is our trademark
Package and delivery
