♦ Built-in PCB control ,duel LED display ,self-programming ,esay and precise operation. ♦ Germany imported DC24V motor,superb performance,high water-proof and long service life. ♦ Protection grade IP65,suitable for severe environment ,working temperature:60℃ to -30℃. ♦ Output power as high as 350 Bar,output distance as long as 50 m. ♦ suitable for grease of various grade.
1- Oil Tank 2- Base 3- Pump Core 4-Motor 5-Gearbox 6-Inlet pipe 7-Outlet Pipes 8-Filter
Product Paramenters
◆ PUMP
Working Temp
－25℃～70℃
Outlet Qty
4
Tank Volume
4L
Oil Feeding
Through Oil Feeding Filter
Lubricant
Maximum Grade NLGI 2
Protection
IP6K 9K acc. To DIN 40050 T9
◆ MOTOR
Working Voltage
380VAC/50Hz
Maximum Output Power
90W
Rotation Speed
1350rpm
Notice: The motor is intermittent rotating.
◆ PUMP CORE
Lubricant Output
6.2cm3/min
Maximum Working Pressure
150bar
Connection Cable
G 1/4
Pipe Diameter
φ6mm
