Ongo 30 tons professional micro small injection molding machine

Product Overview

Description

Ongo 30 tons professional micro small injection molding machine

Z30 TECHINICAL PARAMETERS
INJECTION UNIT		A	B
screw diameter	mm	23	25
shot volume(theoretical)	cm3	38.6	45.6
injection weight(ps)	g	35.1	41.5
injection rate	g/s	25	30
injection pressure	Mpa	211	179
screw speed	rpm	200
CLAMPING UNIT
clamping force	kN	300
open stroke	mm	195
space between tie bars(WxH)	mm	240x210
max mould height	mm	220
min mould height	mm	60
ejector stroke	mm	45
ejector force	kN	13
OTHERS
max pump pressure	Mpa	14
pump motor power	kW	3
heating power	kW	2.5
machine dimension(LxWxH)	m	2.7x0.9x1.5
machine weight	t	1.1





Q1: Are you trading company or manufacturer?
A: We are factory which has over 15 years' manufacturing experience and 80% engineer work have more than 10 years.
Q2: How long is your delivery time?
A: 5 - 20 days after order confirmed. Based on the item and quantity.
Q3: What's the MOQ?
A: 1 set.
Q4: What is your terms of payment?
A: If amount ≤ 1000 USD, 100% in advance, if amount ≥ 1000 USD, T/T 30% as deposit, and 70% balance before shipping. We'll show you the photos of the products and package.
Q5: Where's your general loading port?
A: Ningbo port and Shanghai Port
Q6: Can you do OEM?
A: Yes, we can do OEM.
Q7: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q8: How to deal with the faulty?
A: First, our products are produced in strict quality control system, but if any faulty, we'll send new spare parts for free in one warranty year.
Secondly, our technician will periodically follow up customer to help to do maintenance and ensure equipment operation 7/24 be guaranteed.
Q9: How can get the shipping cost?
A: You tell us your destination port or delivery address, we check with Freight Forwarder for your reference.
