alpha aluminum frame led gypsum led ceiling light
- Category: >>>
- Supplier: Zhongshan Dreamtrip Import & Export Service Co. Ltd.
Share on (62543395653):
Product Overview
Description
alpha aluminum frame led gypsum led ceiling light
Product Description
led module downlight
| Model | Dimension(mm) | Cut out(mm) | Power | Luminous | Packing(mm) | |
| M201-05-9 | 90*83 | 75 | 9W | 720lm | 40pcs/CTN 522*460*230 | |
| M201-05-12 | 90*83 | 75 | 12W | 960lm | 40pcs/CTN 522*460*230 | |
| M202-05-15 | 115*115 | 100 | 15W | 1200lm | 18pcs/CTN 425*395*290 | |
| M202-05-20 | 115*115 | 100 | 20W | 1600lm | 18pcs/CTN 425*395*290 | |
| M203-05-25 | 140*145 | 125 | 25W | 2000lm | 18pcs/CTN 500*470*360 | |
| M203-05-30 | 140*145 | 125 | 30W | 2400lm | 18pcs/CTN 500*470*360 | |
| M204-05-35 | 165*160 | 150 | 35W | 2800lm | 12pcs/CTN 545*386*390 | |
| M204-05-40 | 165*160 | 150 | 40W | 3200lm | 12pcs/CTN 545*386*390 | |
Product Features:
1. Module structure, adapted to different LED light source and beam angles.
2. Different colors and anti-glare designs of reflectors for choice, realizing spot, flood or wallwasher lighting effect.
3. Patented rimless structure, simple but elegant.
4. Secondary calculus lens tech, accurate light distribution , pure layout spot, multianti-glare tech, UGR < 10 .
5. Different drivers for option, non-flicker, smart control, etc.
6. IP20, IP44 for option.
7. Serialized products with multiple dimensions, and powers ranging from 9W to 40W
8. Lifespan up to 35,000 hours, 5 years warranty.
LED Module Series
