Pneumatic O D Ring Butt Welder Rebars Wire Small Butt Welding Machine
- Category: >>>
- Supplier: Suzhou Hanxin Machinery Equipment Co. Ltd.
Share on (62545990323):
Product Overview
Description
Pneumatic O D Ring Butt Welder Rebars Wire Small Butt Welding Machine
Product Description
| Model No. | Power | Mains voltage | Duty cycle | Welding diameter | Max Clamp force | Max upsetting force | Cooling water | Weight | Outline size |
| UN-16 | 16KVA | 380V | 0.2 | 3~5mm | 1600N | 1000N | ≥2.5L/min | 200kg | L850*W500*H1000mm |
| UN-25 | 25KVA | 380V | 0.2 | 3~6mm | 1600N | 1000N | ≥2.5L/min | 225kg | L850*W500*H1000mm |
| UN-40 | 40KVA | 380V | 0.2 | 3~8mm | 1600N | 1000N | ≥2.5L/min | 260kg | L850*W500*H1000mm |
| UN-63 | 63KVA | 380V | 0.2 | 5~10mm | 7500N | 2500N | ≥4.0L/min | 365kg | L1050*W6000*H1300mm |
| UN-80 | 80KVA | 380V | 0.2 | 5~12mm | 7500N | 2500N | ≥4.0L/min | 400kg | L1050*W6000*H1300mm |
| UN-100 | 100KVA | 380V | 0.2 | 5~15mm | 7500N | 2500N | ≥4.0L/min | 450kg | L1050*W6000*H1300mm |
