Automatic recycling machine scrap copper wire and cable granulator (High Quality)
- Category: >>>
- Supplier: Gongyi Jinlonghengji Heavy Industry Machinery Co. Ltd.
Share on (62548438253):
Product Overview
Description
Product Description
Automatic recycling machine scrap copper wire and cable granulator (High Quality)
Waste wire and cable processing equipment, also known as copper rice machine, is mainly used to treat waste communication wires, automobile wires, computer wires, telephone wires, household appliances wires and other oil-free wires. At the same time, pulse bag dust collection equipment is used to effectively control dust overflow and dust removal efficiency is as high 99% to ensure no dust pollution.Main equipment composition of the unit： | ||
1.(Pre-Shredder Machine)Crusher machine single or twin shaft shredder optional | ||
2.Conveyors(belt feeding conveyor and output conveyor with screen) | ||
3.Dust removal system(Big filter) | ||
4.Fanning machine | ||
5.Gravity sorting machine | ||
Applicable materials:
Waste wire and cable processing equipment, also known as dry-type copper meter machine, is mainly used to process waste communication wires, automobile wires, computer wires, telephone wires, household electrical wires and other oil-free wire.Due to the separation of copper particles like rice, it is also known as copper meter machine, which is currently the equipment to reuse waste cables and wires.
Features:
1. Compact structure, beautiful appearance, reasonable layout and convenient installation.
2. The waste wire and cable reuse processing equipment adopts PLC control to make the equipment evenly fed, intelligent operation, and automatic alarm function, which makes the operation easier, saves time and effort, and ensures the stable operation of the equipment.
3. The shredder uses a high-hardness spindle, which makes the crusher more impactful when carrying the load. Its working principle uses a tear-off type, which consists of a miniature cutter head and a cylindrical cutter bar, which greatly reduces the investment of wearing parts (tools).
4. The crusher, sorting equipment and dust collection equipment adopt the platform combination, which makes the equipment easy to move and transport, and increases the flexibility of the equipment.
5. The crusher rotor adopts alternating knife shafts, which makes the crusher more efficient in production, lower in noise and more stable in operation.
6. The waste wire and cable reuse treatment equipment adopts airflow sorting equipment and high-voltage electrostatic equipment to make the sorting rate as high as 99%.
7. The return material system makes the semi-finished product pulverized twice to ensure the complete separation of metal and non-metal.
8. Bag dust collection equipment can effectively control dust overflow, and the dust removal efficiency is as high as 99%. It fully complies with the national environmental protection requirements "Integrated Emission Standard for Air Pollutants" GB16297-1996, without secondary pollution.
2. The waste wire and cable reuse processing equipment adopts PLC control to make the equipment evenly fed, intelligent operation, and automatic alarm function, which makes the operation easier, saves time and effort, and ensures the stable operation of the equipment.
3. The shredder uses a high-hardness spindle, which makes the crusher more impactful when carrying the load. Its working principle uses a tear-off type, which consists of a miniature cutter head and a cylindrical cutter bar, which greatly reduces the investment of wearing parts (tools).
4. The crusher, sorting equipment and dust collection equipment adopt the platform combination, which makes the equipment easy to move and transport, and increases the flexibility of the equipment.
5. The crusher rotor adopts alternating knife shafts, which makes the crusher more efficient in production, lower in noise and more stable in operation.
6. The waste wire and cable reuse treatment equipment adopts airflow sorting equipment and high-voltage electrostatic equipment to make the sorting rate as high as 99%.
7. The return material system makes the semi-finished product pulverized twice to ensure the complete separation of metal and non-metal.
8. Bag dust collection equipment can effectively control dust overflow, and the dust removal efficiency is as high as 99%. It fully complies with the national environmental protection requirements "Integrated Emission Standard for Air Pollutants" GB16297-1996, without secondary pollution.
9. The consumable blades and screens are made of special wear-resistant high-toughness alloy material, which improves the service life and reduces the production cost.
Process flow:
Fully automatic dry copper rice machine (waste wire and cable processing equipment): The shredder is used to break the material into about 3cm in length, and then the second breaker is used to cut and crush, and then sorted by high-precision air flow sorting. The plastic and copper are obtained, and the uncleaned plastic is sorted by an electrostatic separator to ensure the reuse rate of copper. The equipment has a new and unique structure, large production volume and low power consumption. The sorting rate is high, and the feeding is completed at one time, and the cooperation of multiple machines is completed. The entire line is controlled by PLC and is at the leading level in China. The successful development of this machine solves the problems in the method of incineration and copper extraction, improves the quality of reused copper, and can reuse plastics, while avoiding environmental pollution.
Size Information
Technical parameter:
Model | Input size(mm) | Capacity(kg/h) | Power(kw) | Machine Size(mm) | Weight(kg) |
HJTMJ-400 | Φ0.2-Φ20mm | 300-400 | 15 | 1800*1300*1700 | 2850 |
HJTMJ-600 | Φ0.2-Φ20mm | 500-600 | 37 | 2800*1800*2100 | 4200 |
HJTMJ-800 | Φ0.2-Φ20mm | 700-800 | 45 | 2800*2000*2100 | 6500 |
HJTMJ-1000 | Φ0.2-Φ20mm | 800-1000 | 55 | 2800*2500*2100 | 7800 |
Packing&Shipping
TIME IS GOLD.
Packaging Detail:1.Outside package: Standard export wooden cases; 2.Inner package: Stretch film.Delivery Detail:15 working days after placing the order.
Certifications
With us your money is safe.
Related Products
After Sales Service
After-sales service:
Provide considerate services to minimize clients' worries.
Provide considerate services to minimize clients' worries.
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4)Take initiative to eliminate the troubles rapidly at site;
(5) Distribute the guarantee fittings door-to-door;
(6)Provide perfect service;
(7)Provide technical exchanging.
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4)Take initiative to eliminate the troubles rapidly at site;
(5) Distribute the guarantee fittings door-to-door;
(6)Provide perfect service;
(7)Provide technical exchanging.
Company Introduction
Quality is the soul of an enterprise.
Gongyi JinLong Hengji Heavy Industry Equipment Co.. Ltd is a comprehensive enterprise related to design, research and
development,manufacture, marketing, technical support and installation service. We have been concentrating on waste recycling machinery,include scrap cable wire recycling machine, PCB circuit board recycling machine, waste aluminum plastic composite material(aluminum plastic composite panel, medical blister, etc) recycling machine, waste atomobile/air conditioner radiator recycling machine, mixed plastics separation machine. With mature production technology and professional sales, engineers and installation team, through the unremitting technological innovation and following the market demand, we have been installedmachines in more than 50 countries all over the world.
Gongyi JinLong Hengji Heavy Industry Equipment Co.. Ltd is a comprehensive enterprise related to design, research and
development,manufacture, marketing, technical support and installation service. We have been concentrating on waste recycling machinery,include scrap cable wire recycling machine, PCB circuit board recycling machine, waste aluminum plastic composite material(aluminum plastic composite panel, medical blister, etc) recycling machine, waste atomobile/air conditioner radiator recycling machine, mixed plastics separation machine. With mature production technology and professional sales, engineers and installation team, through the unremitting technological innovation and following the market demand, we have been installedmachines in more than 50 countries all over the world.
FAQ
Q: Why Choose Us?
1).Several Year's Experience We have rich experience in equipment manufacturing. Our machines have high reputation both at home and abroad (Such as the Middle East, Southeast Asia, Africa and so on more than 10 countries and regions.)
2).Manufacturer, Not Dealer Factory direct sale makes price more competitive.Customers are always welcome to visit our factory for machine test.
2).Manufacturer, Not Dealer Factory direct sale makes price more competitive.Customers are always welcome to visit our factory for machine test.
3).Fast Delivery: We promise the goods can be shipped out on delivery date after confirmation of the order.
Q:How do I know the quality of your machine?
A: You can send your sample scrap materials to us and we will test the machine for you without charging the fees.And we can send the machine test video to you.We also warmly welcome you to visit our factory to test our machine personally.
Q: When we only purchase one shredder machine production line, can we use it to shred other scrap materials like?
A: Yes, you can. It depends on the difference of blades teeth and quantity, which can be customized.
Q: Which brand of motor will you use?
A: We use domestic motor manufatured by Chinese-famous suppliers, but you can choose Siemens or other brand motor. Don't worry about our machine's quality.
Q: Will you dispatch the engineer to guide installation?
A: Yes, according to the customer's requirement, we will dispatch engineers to guide installation and traning about the operationof the machine.
